Summary of Contents for Bernini Calcata

  • Page 2 This product comes with a one year limited warranty against materials and workmanship. Please review the list of accessories included with your Bernini™ Fountain on the next page. Please note, images of parts are not to scale with one another.

  • Page 3: Table Of Contents

    Contents Step 1: Base and Large Bowl Bowl Locking System Step 2: Fountain Bowl Installation Step 3: Plugging In The Fountain Plugging In The Fountain Inserting Fountain Compartment Door Removing The Fountain Compartment Door Step 4: Setting Up Your Fountain Fill Your Fountain Operating Your Fountain Troubleshooting and Maintenance...
  • Page 4 Parts to your new Bernini Fountain: ™ Large Bowl Plate Electrical Plug Fountain Tier with Connection Port Water Pumps X3 Water Tubes Compartment Door Base Connection 3-Port Leveling Shim Power Cords & Connection Port Cord Splitter Plugs...
  • Page 5 Step 1: Step 1: Step 1: Base & Large Bowl You will need: Large Bowl Base Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 6: Bowl Locking System

    Bowl Locking System A look at how the bowl locking system works on your Fountain. Bottom of large bowl Top of base Note: You will notice that there are two different sized tabs on the bottom of the Large Bowl and there are two corresponding grooves in the top of the Base.
  • Page 7 STOP! At this point, your fountain should look like the im- age below. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 8: Step 2: Fountain Bowl Installation

    Step 2: Fountain Bowl Installation You will need: Plate Assembled Base & Large Bowl Fountain Tier with Water Tubes Remember if you need help contact Customer Care: 1+ (619) 449-2392...
  • Page 9 In the next step you will be installing the Step 1: Feed the Water Pump cord down plate and fountain tier with Water Tubes the pipe. The cord will be connected to the onto the top of the Large Bowl. Connection Port at a later step.
  • Page 10 STOP! At this point, your Fountain should look like the image on the left. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 11: Step 3: Plugging In The Fountain

    Step 3: Plugging In The Fountain You will need: Connection Port Fountain Electrical Plug assembled Power Cords & Connection Port Plugs Door Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 12: Plugging In The Fountain

    Plugging In The Fountain Step 1: In the open Fountain Base, you will see two cords hanging down that you must connect to the Connection Port. If you do not see the two cables inside the Fountain Base, reach up into the Fountain Base and gently pull them down until they are hanging inside the Base Compartment.
  • Page 13 Plugging In The Fountain (Cont.) Connection Port Diagram 1. Black Black (Water Pump) Blue Blue (ABCD Button) Grey Grey (Power) Electrical Connector Diagram 2. ELECTRICAL CONNECTOR Step 4: Ensuring that the three prongs on the Power Cord and the three holes on the Electrical Plug are lined up, screw together the Power Cord and the Electrical Plug, and then plug into any electrical outlet of your choice.

  • Page 14: Removing The Fountain Compartment Door

    At this point, your fountain should look like the STOP! image on the left. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 15: Step 4: Setting Up Your Fountain

    Step 4: Setting Up Your Fountain You will need: Water To Fill Your Fountain Fountain Assembled Remember if you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 16: Fill Your Fountain

    Operating Your Fountain The on-board control panel is located towards the top of the base, just below the Large Bowl. See the diagram below to see how the all-new on-board con- trols work for your Bernini™ Fountain. Manual On/Off 1-4 Hour Timer...
  • Page 17 BUTTON DESCRIPTION Runs the fountain for 1-4 hours with automatic shut off. One hour operation: press the A button once for your fountain to turn on with an automatic shut-off after one hour of operation. Two hour operation: press the A button twice and your fountain will automatically shut-off after two hours of operation.

  • Page 18: Troubleshooting And Maintenance

    You can now try your Bernini™ Fountain to see if everything is working correctly! Turn your Fountain on and if you see water flowing from the outlet in the middle of the Fountain Tier, go to STOP! the next page and select one of the many decorative options for your fountain.

  • Page 19: Cleaning The Water Pump's Parts

    Cleaning the Water Pump’s Parts Water Pump Air Filters After about six weeks of usage, you may want to clean the Water Pump’s filter and impeller to keep your Bernini™ Fountain in tip-top shape. Begin by disconnecting the Step 2: Pull the water Step 3: Wash the filters pump from the Fountain Tier.
  • Page 20 Is your fountain making a loud noise or do you not see water flowing? Try Priming the Water Pump(s) If you find the water pump(s) is running, but water is not flowing from your foun- tain, or you hear a loud grinding noise coming from your fountain, not to worry, you can try priming the water pump(s): Begin by turning your fountain off.

  • Page 21: Using Leveling Shims

    Using Leveling Shims If you are having trouble getting water to flow evenly off of the spouts on your Bernini™ Fountain, you may need to level the surface that your Fountain was placed on. With the included leveling shims, you do not need to move your Fountain, just follow the instructions below to get even water flow.

  • Page 22: Water Pump Connection

    Water Pump Connection If your Water Pumps becomes disconnected for any reason from the Water Tubes inside of the Fountain Tier use these instructions to reconnect your Water Pumps. Step 1: Lift off the Fountain Step 2: Check the connec- Step 3: Ensure that all of Tier and Water Tubes.

  • Page 23: Troubleshooting Guide

    Troubleshooting Guide PROBLEM SOLUTION Check that all connections are properly connected. Fountain Is Not Work- Pump suddenly stops: Check pump is free of debris, kinks or obstructions. See ing or Suddenly Stops Troubleshooting section. Check that all connections are properly connected. Pump not working Check that the connection port cables are secure.
  • Page 24 (1) year from the date of original purchase. If within one (1) year this product fails due to defect in material or workmanship, Bernini™ will repair, replace or supply any defective part at their option. The purchaser must contact Bernini™ and provide a description of the defective part, including digital pictures if requested, with this original purchase documentation as validation of warranty coverage.
