Altronix Trove T1PHK1F4S Installation Manual page 4

1. Mount appropriate Openpath boards into the correct positions by postioning pre-mounted spacers over appropriate holes on the
backplane and depressing down on board to secure spacer to the backplane (Fig. 3, pg. 4).
2. Fasten TC1 backplane to Trove1 enclosure utilizing pan head screws (provided).
Access Controller Position Chart for the Following Openpath Modules:
Openpath
OP-ACC
OP-EX-4E
OP-EX-8E
OP-16EM
Fig. 3
Altronix - eFlow6NB
- BAT +
- 4 -
T1PHK3F8(D): Configuration of Openpath Boards
ON
- DC +
A
B
Altronix - ACM8(CB)
- + - +
NO C NC +IMP -
POWER CONTROL FACP INTERFACE
D
C
T + RET -
Mounting Position
A
B
C
D
Trove Openpath Kits
