Sim-Lab P1-X Instruction Manual page 27

BOX D - Sim Feet
(optional purchase)
HARDWARE KIT
# Part
D1 Feet support plate
D2 Feet
D3 Bolt M8 X 25 DIN 912
D4 Washer M16 DIN 125-A
D5 Washer M8 DIN 125-A
D6 Nut M16
D7 Slot-Nut M8
FRONT MOUNT
(optional purchase)
HARDWARE KIT
F1 Front mount
F2 Front mount side plate LEFT
F3 Front mount side plate RIGHT
F4 Corner bracket 40x40
F5 Corner bracket 40x40 cap
F6 Bolt M8 X 40 DIN 912
F7 Bolt M8 X 20 DIN 912
F8 Bolt M6 X 20 DIN 912
F9 Bolt M8 X 30 DIN 7991
F10 Bolt M8 X 25 DIN 7991
F11 Bolt M8 X 16 DIN 7991
F12 Washer M8 DIN 125-A
F13 Spacer male/female M6 X 10
F14 Slot-Nut M8
F15 Nut M8
QTY Note
4
4 Threaded ball-joint rod fixed
8
8
8
8
8
1
1
1
4
4
4
8
4
4 Countersunk
4 Countersunk
2 Countersunk
12
4
10
14
WHEEL DECK
(optional purchase)
HARDWARE KIT
# Part
W1 Wheel deck
W2 Wheel deck side plate LEFT
W3 Wheel deck side plate RIGHT
W4 Corner bracket 40x40
W5 Corner bracket 40x40 cap
W6 Bolt M8 X 20 DIN 912
W7 Bolt M8 X 16 DIN 912
W8 Bolt M8 X 25 DIN 7991
W9 Bolt M8 X 16 DIN 7991
W10 Washer M8 DIN 125-A
W11 Nut M8
W12 Slot-Nut M8
SIDE MOUNT FOR FANATEC
PROFILE KIT
SP1 80X40 Length=DD1 or CSL version
HARDWARE KIT
S2 Side mount base holder LEFT
S3 Side mount base holder RIGHT
S4 Side mount profile holder LEFT
S5 Side mount profile holder RIGHT
S6 Bolt M8 X 20 DIN 912
S8 Bolt M6 X 20 DIN 912
S9 Bolt M8 X 20 DIN 7991
S10 Bolt M6 X 20 DIN 7991
S11 Washer M8 DIN 125-A
S12 Washer M6 DIN 125-A
S13 Slot-Nut M8
Disclaimer: for some entries on this list, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
QTY Note
1
1
1
4
4
8
4
8 Countersunk
2 Countersunk
18
10
10
(optional purchase)
2 Threaded M8
1
1
1
1
8
4
8 Countersunk
4 Countersunk
8
6
8
27
