Sim-Lab P1-X Instruction Manual page 26

BOX A
PROFILE KIT
# Part
AP1 160X40 Length=1350mm
AP2 160X40 Length=500mm
AP3 120X40 Length=780mm
BOX B
PROFILE KIT
BP1 80X40 Length=580mm
BP2 40X40 Length=500mm
BP3 40X40 Length=320mm
BP4 40X40 Length=200mm
HARDWARE KIT
B5 Sandwich plate large
B6 Sandwich plate small
B7 Rubber Feet
B8 Corner bracket 40x40
B9 Corner bracket 40x40 cap
B10 Profile 160x40 end-cap
B11 Profile 120x40 end-cap
B12 Profile 80x40 end-cap
B13 Profile 40x40 end-cap
B14 Bolt M8 X 25 DIN 912
B15 Bolt M8 X 20 DIN 912
B16 Bolt M8 X 16 DIN 912
B17 Bolt M6 X 20 DIN 912
B18 Bolt M6 X 12 DIN 912
QTY Note
2
2
2
1
2
1
2
2
1
4
20
20
4
4
1
9
8 Bag HW 40.D
10 Bag HW 40.D
50 Bag HW 40.C
8 Bag HW 40.D
4 Bag HW 40.D
# Part
B19 Bolt M8 X 25 DIN 7991
B20 Bolt M8 X 20 DIN 7991
B21 Washer M8 DIN 125-A
B22 Slot-Nut M8
B23 Slot-Nut M6
B24 Slot-Nut M5
B25 Slot-Nut M4
BOX C - Pedal Tray
PROFILE KIT
CP1 160X40 Length=470mm
CP2 80X40 Length=470mm
HARDWARE KIT
C3 P1-X pedal plate LEFT
C4 P1-X pedal plate RIGHT
C5 Bolt M8 X 25 DIN 912
C6 Bolt M6 X 16 DIN 912
C7 Bolt M5 X 16 DIN 912
C8 Bolt M8 X 25 DIN 7991
C9 Washer M8 DIN 125-A
C10 Slot-Nut M8
C11 Slot-Nut M6
C12 Slot-Nut M5
Disclaimer: for some entries on this list, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
QTY Note
12 Countersunk, Bag HW 40.D
20 Countersunk, Bag HW 40.D
10 Bag HW 40.D
65 Bag HW 40.A
12 Bag HW 40.B
4 Bag HW 40.D
4 Bag HW 40.D
1
1
1
1
10
12
12
10 Countersunk
10
10
12
12
26
26 28 |
