- Page 1 XERO-PLAY™ Steering Wheel Quick Release INSTRUCTION MANUAL SLA108 SLA109 SLA110 SLA111 SLA112 SLA113 SLA114 SKU: https://sim-lab.eu/shop/product/xero-playtm-steering-wheel-quick-release-1255 info@sim-lab.eu Copyright© 2021 - Sim-Lab Products | Revision 0.9...
- Page 2 Mounting base side adapter Mounting wheel side adapter * 2x B5 nuts, B6 washers and B7 bolts are spare ones ** Length of the bolts depends on the thickness of your wheel. 6x** B2/B3/B4...
- Page 3 Connecting wheel side and base side adapters Ensure that the quick release lever is unlocked Insert wheel side into the base side Lock the lever...
- Page 4 Adjusting the grip In order to adjust the grip: Loosen bolt Adjust bolt (slowly until lever force is OK) Tighten bolt...
- Page 5 Final product* * Users wheel and wheelbase may vary...
-
Page 6: Parts List
Parts list Base Adapter (Motor side) - Black / Red / Blue Part No. Part name ZY-01 Body VB2 (black/red/blue) Units Bolt - DIN 912 (Black steel, 20mm, M5) Units Nut (M5, DIN 985 locknut, Galvanised) Units Washer (Black steel, M5, Plain black) Units Wheelside Adapter - 52mm / 70mm / 50.8mm / 44.5mm Part No.
