Table Of Contents - GE Profile Advantium SCA2001KSS Installation Instructions Manual

CONTENTS
General information
Important Safety Instructions ........................................ 3
Electrical Requirements.................................................. 3
Hood Exhaust ............................................................ 4, 5
Damage-Shipment/Installation.................................... 6
Parts Included ................................................................ 6
Tools You Will Need ...................................................... 7
Mounting Space .............................................................. 7
Step-by-step installation guide
Placement of Mounting Plate .................................. 8-10
Removing the Mounting Plate ........................ 8
Finding the Wall Studs...................................... 8
Determining Wall Plate Location .................... 9
Aligning the Wall Plate .................................. 10
Installation Types .................................................... 11-22
A
Outside Top Exhaust ................................ 12-14
Attach Mounting Plate to Wall ..............12
Preparation of Top Cabinet ..................13
Assemble and Install Adaptor ................13
Mount the Oven ..............................13, 14
Adjust the Exhaust Adaptor ..................14
Connecting Ductwork ............................14
B
Outside Back Exhaust .............................. 15-18
Preparing Rear Wall for
Outside Back Exhaust ............................15
Attach Mounting Plate to Wall ..............16
Preparation of Top Cabinet ..................16
Adapting Blower for Outside
Back Exhaust ....................................16, 17
Mount the Oven ..............................17, 18
Installation Instructions
C
Recirculating ............................................ 19-22
Attach Mounting Plate to Wall ..............19
Preparation of Top Cabinet ..................19
Adapting Blower for
Recirculation ....................................20, 21
Mount the Oven ..............................21, 22
Installing the Charcoal Filter ................22
Before You Use Your Oven ........................................ 23
2
