Venetia - 1 Drawer Bedside
Assembly Instructions -
Dimensions
Width - 38.5cm
Depth - 36cm
Height - 42cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928
or email: Help@ClickSpares.co.uk (quoting your original order number)
Please keep for future reference
630/3505
630/3495
630/3512
630/3488
632/5394
632/5404
632/5411
632/5428
MADE IN
BRITAIN
Issue 2 - 29/07/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Venetia 630/3505 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos Venetia 630/3505

  • Page 1 Venetia - 1 Drawer Bedside Assembly Instructions - 630/3505 Please keep for future reference 630/3495 630/3512 630/3488 632/5394 632/5404 632/5411 632/5428 Dimensions Width - 38.5cm Depth - 36cm MADE IN Height - 42cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number) Issue 2 - 29/07/13...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: These units weigh • Make sure you have enough • We do not approximately 8kgs. Please lift space to layout the parts before recommend the with care.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the panels listed below Left Side Right Side (D0622A) (D0623A)
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Step 1 Prepare the drawer front Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten metal...
  • Page 6 Assembly Instructions Step 5 Attach the drawer front Turn the drawer assembly over and push onto the back of the drawer front Note: Turn locking nuts clockwise to Note: The locking nuts can be on secure panels - more either surface of the drawer sides. than 1/2 a turn.
  • Page 7 Assembly Instructions Step 8 Prepare the left and right side F600 10mm Separate the runners Push fit the left runner marked ‘L’ into the holes shown on the left side Note: Runners must be be fitted flat against the Finished panel.
  • Page 8 Assembly Instructions Step 9 Plain chipboard surface Prepare the base Tap a wooden dowel into each side of the base Step 10 Prepare the plinth Plain chipboard surface Tap a wooden dowel into each end of the plinth Step 11 Fit the base and the plinth to the right side Attach the base...
  • Page 9 Assembly Instructions Step 12 Fit the left side Attach the left side the assembly and secure with 3 screws Step 13 Plain chipboard surface Prepare the top Screw 2 metal dowels into the holes shown on the top Step 14 Fit the top Push the top onto...
  • Page 10 Assembly Instructions Step 15 Fit the back panel The measurement from top corner X to bottom corner X must be Square up the unit by equal to the measurement from top corner Y to bottom corner Y making sure that measurement x to x equals y to y.
  • Page 11 If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers on the component pages) Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
  • Page 12 ALR2529...
