Starting Service level SCC

1) Switch on unit
on
2) Set DIP 1 on operator PCB to „"ON"" position
1 2 3 4
3) Press service key
4) On the displays the following available Service - modules will be shown

Diagnostic

Running Times
Basic Settings
Function Test
5) Activate selected service module by push on display or push on central dial
1 - DIAGNOSTIC
Cabinet B1
Garraum
130°C
RESET
act
Starting with software version 01-07-02 gas related information is not shown on electric units!
8) Function data entry through central dial: press dial icon first, frame will turn to red ==>
only no the value can be changed.
on
9) Set DIP 1 on operator PCB to "OFF" position to deactivate Service level
1 2 3 4
6) Deactivate selected service module by pushing on "return"
symbol
7) Returning to SCC display / cooking mode only possible from
Diagnostic mode!
345°C
max
