iReal 2s Handheld Color 3D Scanner User Manual
Table 5- 3 Scan interface button function
Window Button Function
Select the point calculation button, select two or more points, and
press the distance between the points and the angle formed by the
line segments connected between the points. Click the button
again to exit the point selection calculation mode.
Select surface calculation button, select a part of the triangle
surface to calculate the corresponding three-dimensional surface
area, and click the button again to exit the surface selection
calculation mode.
Left toolbar
Under the color model, click the color magic wand, set the
（extensions）
tolerance value in the dialog box, and intelligently distinguish the
colors on the model to achieve the intelligent selection of the
triangular surface for calculating the three-dimensional surface
area.
Note: The selected area and the area outside need to have
obvious pixel differences and sharp edges.
Subdivide each triangle to increase the number of triangles in
the mesh data.
Withdraw the current frame scan data. If it is selected by
mistake, left-click to cancel the selection.
When the scan is paused, the data can be processed by point cloud
Left tool bar filtering, global accurate stitching, etc., and the scanned data can
be observed more clearly.
Note: The editing and deletion of point cloud data can only be
performed after the scan is finished.
27
