iReal 2s Handheld Color 3D Scanner User Manual
Table 5- 3 Scan interface button function
Window Button Function
Clear the data and select rescan according to the current mode.
Open the scan data and enter the browse mode.
Turn on the device beep, and the buzzer will emit a beep when
the device scans beyond the scan specific or cannot be spliced.
Turn off the device beep sound. When the device scans beyond
the scan specific or cannot be spliced, the buzzer will not make
Menu
sound.
Import a valid management profile
Splice two different project files together through common
features.
Language: software interface language can be switched, help:
provide help information; about: display software, hardware
version, authorization information, copyright information, etc.
Pre - scan button. Familiarize yourself with the best scanning
distance of the device. Adjust the camera brightness to ensure
the maximum point cloud out. Click again to stop pre - scan and
start the first frame scan.
Point the scanner at enough geometric features / patterns /
Left tool bar
marking points of the scanned object, and click the button to
start the first frame scan.
Note: If there is less scan data in the first frame or the scanner is
not aligned with the object under test, splicing failure may
result.
