- Page 1 3DeVOK MT Handheld Color 3D Scanner Quick Guide V1.0...
-
Page 2: Product List
1. Product List 3DeVOK MT Master Plate (with 4 Expansion Accessories) Grey Card Power Data Cable Power Cable (with plug), Power Adapter Reflective Marker（ s D3mmx500pcs; D6mmx2000pcs） Stickers for Hybrid Alignment Carry Case USB Stick (with Scanning Software) Scanning Sample (for Detail Verification) - Page 3 34 Blue Laser Lines 22 Infrared Laser Lines （invisible） Infrared Vcsel Structured Light （invisible） Light Sources Class of Lasers Class Ⅱ (Eye-safe) Class Ⅰ (Eye-safe) Infrared Linear-array Structured Crossed Infrared Lasers Light (Speckle) Crossed Blue Lasers Scan Mode (Supports markerless and invisilbe-light (Supports markless, invisible-light, fine (Supports markerless scanning) scanning)
- Page 4 The Ability for Supports .stl, .obj and other formats 3D Printing Working Temperature 0 - 40℃ Range Working Humidity 10% - 90% RH (Non-condensing) Range Interface USB 3.0 Scanner Dimensions Dimensions: 215 mm × 73 mm × 53 mm; Weight: 620 g &...
- Page 5 Infrared light supplement Blue light supplement Black and white camera LED light supplement Touch screen Color camera Blue laser emitter Infrared laser emitter Infrared VCSEL Black and white camera...
-
Page 6: Touch Screen
White model/ Touch Screen color model/ Infrared fine scan View lock on/off color map Start Light strip on when start scanning decrease Exposure Increase decrease Scanning Increase display... - Page 7 1.Insert the USB drive provided in the case to PC, find the 3DeVOK Studio Installer and install. Future updates to the installation can be obtained from the official website: www.3devok.com. Note: The initial activation time will be related to the warranty period. For details, please refer to the device ...
- Page 8 1. Connect one end of the USB cable to USB 2. Connect the power cable and the power adapter 3. The connection of device, data cable, 3.0 port (the blue port) of PC (if it is a desktop, to the power source, and connect the round plug at power adapter, power cable, and PC is it should be plugged into the USB 3.0 port at the end of the power adapter to the round...
- Page 9 1. Open the 3DeVOK Studio software, and it will first prompt for 2. After the update, the device is successfully connected, and the the import of a new configuration file. Click the “Yes” button, software interface is displayed as shown in the figure below. The the software will automatically import the configuration file scanning mode can be selected at the left sidebar (left white and restart for the update.
-
Page 10: Device Calibration
Device Calibration Laser Plane Calibration 1. Take out the Expansion 2. Click for device calibration, After standard calibration, if there is deficiency of laser lines or accessories from the case, excessive noise data during scanning, the laser plane calibration of the and follow the steps (shown in the assemble it, and place it device needs to be performed. - Page 11 Scan 1. Select the scanning mode, then click to start, or click the ▷ button on the center of the screen to begin scanning. Keep the device at the optimal scanning distance and scan the object at different angles until the object’ s color map turns green. Mode Guide: Structured light Scan: Suitable for human body scanning, as well as fast scanning of medium-to-large objects.
- Page 12 For more tutorials on 3DeVOK products and software updates, please visit the official website: https://www.3devok.com/...
- Page 13 Building 12, No.998, West Wenyi Road, Yuhang District, Hangzhou, Zhejiang Province, China E-mail: iad@3d-scantech.com Tel: 0571-85370380 After-sales department email (for equipment malfunctions, connection issues, etc.): support@3d-scantech.com After-sales Tel: +86 400 880 8059 ext. 2 Working hours: 9:00 AM to 6:00 PM (GMT+8), Monday to Friday,closed on holidays...
