5 Operation
52
Parameter
E+H Matrix
(CW II)
Gap
Tag no.
VAH0
Profile revision
VAH1
Version string
VAH2
Gap
Serial no.
VAH4
Distance unit
VAH5
Gap
Download mode
VAH8
Data strings
In der Slot/Index table some data types, e.g. DS-33 are marked by an asterisk. These
are data strings according to the PROFIBUS-PA specifications part 1, Version 3.0. They
contain several elements, which are addressed by an additional subindex. The
following table gives an example.
Data type
DS-33
Levelflex M FMP 40 with PROFIBUS-PA
Slot Index
Size
[bytes]
1
237
1
238
1
239
1
240
1
241
1
242
1
243
2
1
244 - 245
1
246
1
Subindex
Typ
1
FLOAT
5
UNSIGNED8
Type
Read Write Storage
STRING
x
STRING
x
x
STRING
x
STRING
x
x
UNSIGNED16
x
x
UNSIGNED8
x
x
Size [bytes]
4
1
Endress+Hauser
Class
const
static
const
static
static
static
