EMOJO Caddy Owner's Manual page 17

Read the instructions carefully to identify and understand the components of the electric bicycle such as pedal, seat post etc. and the name of relevant spare parts.
When specialized servicing of bike is required, please go to an authorized EMOJO repair shop or store or another trusted bike professional.
1. Assembly of the front wheel unit:
Identify the nuts and the lock washers (Fig A) necessary for the front axle assembly.
Assemble the front wheel unit onto the front fork, pass the lock washers thru the axle and lock the tab into the groove of the front fork (fig. B). Tighten the nuts on
both sides of the hub with a wrench (fig C). Attention: when assembling, make sure the disc brake and the brake caliper are on the same side (left side), the disc
brake must slide into the gap between the two brake pads of the disc brake caliper, make sure the wheel turns freely and does not rub against the brake pads when
the front brake is not been pressed.
Fig A.
2. Adjustment of Saddle:
Adjust the saddle to the proper height. Using the
socket hand wrench, lock the fixed screws on the seat post
and clamp tightly. Please note that when adjusting the
height of the standpipe and seat post, it has to keep the
inserting depth above the safety line.
Front wheel installation
Fig B. Fig C.
Free rotation between disc
and caliper.
Safety Line
15
