2.3 Tango-Utilities

Tango-Utilities is the basic software to configure Tango_Plus and export values from measurements. It is
not meant to perform further analysis calculations. For configuring the device via PC, you have to install the
Tango-Driver and Tango-Utilities software first (section 1.7). Tango-Utilities contains a line for main menu
and a line with buttons for: Stop, Run/Pause, Store/Not Store, Set Marker and start calibration. At the bottom
the Tabs are located and the status bar.
Figure 2.1: Tango-Utilities view: Main menu, buttons, working area, Tabs, Status bar

2.3.1 Status bar

The status bar displays various status information from left to right:
Connection Status:
disconnected, connected, but Tango_Plus off, connected, Tango_Plus on;
Virtual COM Port;
Measurement Status: Stop, Measurement, Pause;
blinken
Record Status: Record-Mode off, Record-Mode on, Record-Mode on (Recording);
Marker Status: MARK;
Memory usage: per Hour, Day and Week

2.3.2 Program settings and Extended device settings

Via the main menu Settings->Program. . . the following settings are available (figure 2.2): Selection of the
connected device Tango_Plus (Connected Device), default export directory (Default Export Directory)
and the default directory for configuration data. The Extended device settings cannot be adjusted manually
without PC.
Figure 2.2: Tango-Utilities - Program settings Figure 2.3: Tango-Utilities- Extended device settings
