SINUS Tango Plus Manual page 13

Item
Measurement
Record Mode
Sync at Full Hour
Fixed Duration
Repeat Mode
Repeat Interval
Start Time
Calibration
Start Calibration
Calibration Level
Reset Calibration
Measurement Values
Display Location
Display Interval
Storage Interval
Print Result
Octave Spectrum
Octave Mode
Display Range
Display Weigthing
Display Interval
Storage Weigthing
Storage Interval
History Graph
Display Range
History Time
Graph 1
Graph 2
Storage Files
Stored Files
Reset Storage File ID
Erase all Storage Files
Device
Time
Display
Panels
Options
Info
Reset Configuration
Print Results
Table 2.2: Manual configuration menu of Tango_Plus
SINUS Messtechnik GmbH
2.2 Device configuration
Description
Select values to be stored or just displayed.
Synchronize time intervals to full hours.
Measurement ends after a fixed time.
If a Fixed Duration is specified an automatic repeat can be enabled.
If a Fixed Duration is specified and the Repeat Mode is enabled, an interval must be configured
in which the measurement is repeated. So can be configured for example to measure every day
for 1 hour at 6 o'clock.
Predefine a time to start the measurement automatically.
Start the process of calibration.
Set the calibration level (94.0 dB, 104.0 dB, 114.0 dB, Other).
Reset the calibration level to factory value.
(Select a sound level e.g. L
AFmax
Select on which graph the value shall be shown.
Select the rate of display refresh (500 ms, . . . , 60 min, End Result only).
Set the storage interval (No storage, 62.5 ms, . . . , 60 min, End Result only).
Decide whether the result shall be printed.
Select whether 1/3 or full octaves shall be measured.
Adjust the scaling of the Y-axis.
Available weigthings: Z, A, C
Select the rate of display refresh (125 ms, . . . , 60 min, End Result only).
Available weigthings: Z, A, C
Set the storage interval (No storage, 125 ms, . . . , 60 min, End Result only).
Adjust the scaling of the Y-axis.
Adjust the scaling of the X-axis.
Select which value shall be displayed as yellow.
Select which value shall be displayed as green.
View Results, Delete File
Resets File ID to the smallest possible number, so that no gaps are filled with new measurements:
Assume stored measurements are labled with IDs 1 to 6. If for example measurements 3, 5, and
6 are deleted and the File ID is reset, the next measurement will be labled with the number 5.
Clear all Files.
Set time and select 12h or 24h format.
Set Display properties.
Set, whether Panels should be displayed or not:
Octave Spectrum, History Graph, Results, Measurement Info
Additional configurational settings:
Microphone Connection (Direct connection, cable connection, Weather Protector)
Power (automatic: On by USB, On by Reset, Off by Inactivity)
Provides information about firmware and hardware (see also figure 1.6).
Reset to factory settings.
13 of 47
and adjust the following properties.)
