5. Having finished you are asked to adopt the new calibration values. If something went wrong, an error
message appears.

2.4.2 Calibrate Tango_Plus directly

1. Switch on the device.
2. Press the Setup-Button and navigate to the calibration menu.
3. Adjust the calibration level and execute "Start Calibration". The reference calibration level will be
blinking on the display (e.g. 94 dB). You may adjust this value with the Scroll-Button (94 dB, 104 dB
or 114 dB).
4. Switch on the calibrator (select the correspondig level on the calibrator, if necessary) and insert the
microphone into the calibrator.
5. Press the OK-Button and Calibration starts. First, the noise level of the device is measured and second
the calibrator signal. During calibration,
calibration is finished. The measured level is displayed enabling you to check the calibration result.
6. Press the OK-Button to save the new sensitivity value or press the Setup-Button to reject.
7. You have left the calibration menu and the device is in STOP-Mode.
If the calibration has been affirmed the symbol
NOTICE!
NOTICE!
Manual Tango_Plus
2 APPLIANCE
is blinking on the display. When
is shown on the display until the next start of Tango_Plus.
If the new value deviates more than 3 dB from the last one, it is not accep-
ted. The message "Error" is displayed in this case. This tolerance is redu-
ced to 1.5 dB for approvable devices.
Figure 2.15: Calibration menu
On the device you can reset the calibration result to factory value via:
"Menu > Calibration > Reset Calibration".
22 of 47
stops blinking, the
