2.3.8 Data export

Measured data are saved to the internal storage of the device (32 MB). The data sets are listed in the
Data-Tab (section 2.3.7). By right-clicking you may open a context menu, that provides access to the Export
window (figure 2.10).
History Data tab
This tab provides the export of time histories of level or spectra to the Excel compatible csv format. To use
it, check the "Enable Export file" box. You may specify the name, check automatic attributes to be given to
the export file name and select the values, which that file should contain. Via the
create more History Data tabs, to get several different configured export files from the same measurement
in the same export process.
Figure 2.10: Export - History Data
NOTICE!
Result List tab
Enable this way of export to collect Endresults of all exported measurements in csv format. The configuration
is similar to the History Data tab.
SINUS Messtechnik GmbH
2.3 Tango-Utilities
If the set intervals do not fit exactly into the hourly grid for a synchronized
measurement, the data of the last interval will be marked accordingly.
19 of 47
button, you can
Add File
Manual Tango_Plus
