Deviation from original factory calibration (checked during calibration but not saved)
Loss of calibration status is effected by:
Switching off the device (except when the measurement start is scheduled with a preset start time)
Switch off the device during measurement breaks in repeat mode
Cancel of calibration

2.5.4 View measurement results on Tango_Plus

It is possible to view the measurement results on the device via: "Menu > Stored Files > [File] > View
Results". There you find resulting level and resulting 1/3 octaves as well as information about calibration
status, microphone sensitivity and whether the microphone was dircetly connected or detached.

2.5.5 Print results

If a printer is connected, you may set results to be printed after the measurement (section 2.2.1) under:
Functions > Measurement Values > [Value] > Print Result. This is possible for all sound levels that result in
one number like for example
You may also recall a measurement and print the result via: Functions > Print Results.
Manual Tango_Plus
2 APPLIANCE
or . You are asked to print after each measurement automatically.
Aeq CF max
24 of 47 SINUS Messtechnik GmbH
