Vacuum time
min
20
A 20-minute vacuum phase will be suggested.
Use UP-DOWN buttons to select the desired value. Confirm by pressing ENTER.
System leaktightness
control min.
A 4-minute system leak test will be suggested at the end of vacuum phase. .
Use UP-DOWN buttons to select the desired value. Confirm by pressing ENTER.
Inject oil-UV? Yes
Select using UP-DOWN buttons. Confirm by pressing ENTER.
If NO option is selected, the station will suggest going into filling phase.
If YES option is selected, the following message is displayed:
Manual Oil-UV
Synchro. Oil-Uv
Select using UP-DOWN buttons. Confirm by pressing ENTER.
If synchronized oil-UV feeding option is selected, the station will suggest switching into
Synchronic oil-UV feeding phase.
See 9.5.2 Synchronic oil-UV feeding.
If Manual oil-UV option is selected, the following message is displayed:
Specify refrigerant weight
Refrig.
g.
Use UP-DOWN buttons to enter refrigerant quantity. Confirm by pressing ENTER.
Start operation?
Confirm by pressing ENTER.
Manual Oil-UV
Synchro. Oil-Uv □
Use UP-DOWN buttons to select Manual Oil-UV. Confirm by pressing ENTER.
After the vacuum phase the station will stop to allow manual feeding of oil -UV.
4
No
■
□
700
8.5 Synchronic oil-UV feeding.
8.5.1
Manual oil-UV feeding.
■
