Replas LYREBIRD LBS-1800FS Assembly Instructions

IMPORTANT: Please read carefully before assembling.
LYREBIRD
SETTING
1.8m
Free Standing
TABLE:
1. Place Table top face down on a flat surface.
2. Place supports into position. Ensure that the table lugs on the outside supports are facing towards
the centre of the table.
3. Secure table supports to the 40x200mm planks using the 65mm hex screws.
NOTE: Do not fully tighten screws until all are in position.
4. Insert crossarm into the support lugs. Then, using approx 4.5mm drill bit, drill a pilot hole into
crossarm and secure using 65mm Hex screw.
NOTE: Ensure that all legs are square before drilling pilot hole.
BENCHES:
1. Place bench slats face down on a flat surface.
2. Using the 75mm Hex screws supplied, secure each bench support to the slats.
3. Once all screws have been tightened, turn setting over and place into position.
TABLE:
1 X Table Top ‐ pre‐assembled
3 X Table Supports
1 X Table Crossarm
30 X 14g x 65mm Hex Head screws
If you require further installation assistance, please contact your supplier.
ASSEMBLY INSTRUCTIONS
COMPONENTS LIST
BENCHES:
2 X Bench Tops ‐ pre‐assembled
6 X Bench Supports
36 X 14g x 75mm Hex Head Screws
