Replas LYREBIRD SETTING Assembly Instructions

IMPORTANT: Please read carefully before assembling.
LYREBIRD
SETTING
1.8m Free Standing
Wheel Chair Access

TABLE:

1. Place table top face down on a flat surface.
2. Place Table supports inside metal frame.
Note: Ensure that the table legs have the lugs facing towards the centre of the table.
4. Using a 3.5mm drill bit, drill into the support through the pilot holes in the metal frame.
5. Using the 40mm Hex Screws supplied, screw support onto frame, taking care not to over tighten as this
could strip the thread in the support.
NOTE: Use a spirit level to ensure that all legs are square before drilling pilot holes.
6. Insert crossarm into the support lugs. Then, using approx 4.5mm drill bit, drill a pilot hole into crossarm
and secure using 65mm bugle screw.
NOTE: Use a spirit level to ensure that all legs are square before drilling pilot holes.

BENCHES:

1. Place bench slats face down on a flat surface.
2. Attach bench supports to the 40x90mm slats using the 75mm hex head screws.
3. Once all screws have been tightened, turn setting over and place into position.
TABLE:
1 X Table Top - pre-assembled
2 X Table Supports
1 X Table Crossarm
16 X 12g x 40mm Hex Head screws
4 X 14g x 65mm Hex Head screws
ASSEMBLY INSTRUCTIONS
Components List
If you require further installation
assistance, please contact your supplier.
www.replas.com.au
BENCHES:
2 X Bench Tops - pre-assembled
6 X Bench Supports
36 X 14g x 75mm Hex Head Screws
