- Page 1 ELINA time flow thermostatic bar mixer shower Installation and operating instructions nstallers please note these InstructIons are to be left wIth the user 2180660G July 2008...
-
Page 2: Table Of Contents
Spare parts .................. 14 Maintenance ................15 Fault Finding ................16 - 17 Guarantee, service policy, etc...........rear cover To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone: 0844 980 0730... -
Page 3: Main Components
Time Flow Thermostatic bar mixer shower MAIN CoMPoNENts Fig. Filter Threaded retainer Long thread fitting Flow regulator: check facing Time Flow thermostatic bar mixer valve Cover trim (2 off) Long thread straight connector including: - Flow regulator - Filter All dimensions listed in this fitting book regarding the product and installation are approximate. *All kits are for illustration purposes only and are not supplied unless otherwise stated. -
Page 4: Introduction
‘site requirements’. d. Do Not connect the mixer shower to a gravity hot supply and a mains cold supply Replacement parts can be ordered from Triton Customer (or vice versa). Service. See ‘spare parts’ for details and part numbers. - Page 5 Do Not solder fittings near the mixer unit have to be fitted. For advice on the Triton as heat can transfer along the pipework and scale inhibitor, please contact Customer damage the mixer valve.
-
Page 6: Typical Domestic Installations
Time Flow Thermostatic bar mixer shower tYPICAL CoMMERCIAL INstALLAtIoNs *Fig. (diagrammatic view – not to scale) Commercial gravity fed systems (fig.) Vent Cold feed to Calorifier The shower control MUST be fed from a cold Cold water to taps water cistern and hot water cylinder providing Cold water cistern nominally equal pressures. -
Page 7: Siting Of The Shower
Time Flow Thermostatic bar mixer shower sItING oF tHE sHoWER AND *Fig. (diagrammatic view – not to scale) ACCEssoRIEs Refer to (fig.) for correct siting of the shower. The mixer valve should be positioned, as detailed, with all controls within comfortable reached of the user. -
Page 8: Straight Fittings
Time Flow Thermostatic bar mixer shower stRAIGHt FIttINGs Fig. The supply pipes can be routed from the side, rising, rear or falling and must end in suitable fittings (fig.) to accept the long thread connectors. The straight connectors can be used to connect to ½”... -
Page 9: Making Good
Time Flow Thermostatic bar mixer shower MAKING GooD Fig.8 Make good the wall and complete the tiling. FIttING tHE MIXER Filter Threaded Offer the shower valve to the fittings and, retainer checking that the sealing washers are place, screw the unions onto the fittings. FLoW REGULAtIoN Long thread fitting... -
Page 10: Commissioning
Time Flow Thermostatic bar mixer shower CoMMIssIoNING Fig.9 Make sure that both the hot and cold water supplies are fully open and at (or near to) their design temperature and pressures, and are within the requirements as stated. Set the temperature control (left-hand side) to maximum temperature setting, see (fig.9). -
Page 11: Adjusting The Maximum Temperature Setting
Time Flow Thermostatic bar mixer shower ADJUstING tHE MAXIMUM Fig. tEMPERAtURE oVERRIDE sEttING Remove the temperature control knob to allow access to the temperature control spindle (fig.). Turn the temperature control spindle anti- Spindle clockwise and press the time flow button (the button can be held in to allow for more time to adjust the setting). -
Page 12: Operating The Shower
Time Flow Thermostatic bar mixer shower oPERAtING tHE sHoWER Fig. Rotate the temperature control (left-hand side) anti-clockwise to the desired temperature (fig.). To start the shower, press the time flow button located on the right hand side of the unit all of the way in and then release (fig.). -
Page 13: Approvals
Time Flow Thermostatic bar mixer shower APProvAls This mixer valve has been designed to comply with the requirements of: Bs EN WRAs FLoW CHARt Pressure/Flow rate l/min • Flow rate at 38°C • Flow control fully open • Open outlet •... -
Page 14: Dimensions
Time Flow Thermostatic bar mixer shower DIMENsIoNs 56mm All dimensions listed in this fitting book regarding the product and installation are approximate. -
Page 15: Bar Mixer Fittings
Time Flow Thermostatic bar mixer shower *BAR MIXER FIttINGs ref. Description Part No. A. Bar bracket UNBMXBKT B. Bar bracket, exposed UNBMXFIXEX C. Bar bracket, push-fit UNBMXFIXBT D. Straight connector (supplied) 86001120 E. Dogleg connector 86001110 * Not supplied unless otherwise stated... -
Page 16: Spare Parts
Time Flow Thermostatic bar mixer shower sPARE PARts ref. Description Part No. 1. End trim and screw 83312710 2. Temperature control knob kit 83312200 3. Thermostatic cartridge kit 83312190 4. Outlet hose fitting 83312220 5. Time Flow cartridge kit 83312180 6. -
Page 17: Maintenance
Time Flow Thermostatic bar mixer shower MAINtENANCE Cleaning Triton recommends that all products are cleaned The following maintenance procedure must using warm, soapy water. be carried out for commercial and health care premises, but is not necessarily required for Do not use abrasive or aggressive chemical domestic installations. -
Page 18: Fault Finding
1.4 Cold water supply 1.4.1 Turn off the shower and consult a compe- blocked. tent plumber or contact Triton Customer Service. 1.5 High volume of cold 1.5.1 Reduce the simultaneous demand from the water drawn off else- supply. - Page 19 Time Flow Thermostatic bar mixer shower FAULt FINDING Problem/symptom Cause Action/Cure 4 Water does not 4.1 Water supplies cut off. 4.1.1 Check water elsewhere in house and if flow or shower necessary contact local water company. pattern collapses 4.2 Shower unit blocked. 4.2.1 Inspect the inlet filters.
- Page 20 0844 980 0730 Triton Road Fax: 0844 980 0744 Nuneaton Warwickshire CV11 4NR www.tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited E-mail: serviceenquiries@tritonshowers.co.uk 29-5-2009 TRITON reserve the right to change product specification without prior notice. E&OA. © TRITON SHOWERS 2009...
