Installation of 4-way mixing valve actuator (only PelTec-lambda 69/96)
Valve is 100% closed
Valve is 50% opened/closed
Valve is 100% opened
Technical instructions PelTec-lambda
Flow from
the boiler
Return to
the boiler
Flow from
the boiler
Return to
the boiler
Flow from
the boiler
Return to
the boiler
Flow to the
installation
Return from
installation
Flow to the
installation
Return from
installation
Flow to the
installation
Return from
installation
83
