Centrometal PelTec 12 Technical Instructions page 71

Cleaning interval
At least once per year
1
1. Maintenance
1.
Man. Boiler Cleaning
2.
Filling feeder screw
3.
Airvent
1. Press ''Maintenance'' on the regulation and then ''Cleaning the boiler''.
2. Press ''START'' (it will start the fan and it will open a grate.)
3. Lift the top cover (D), then unscrew the four screws and remove the
upper door (E).
4. By using scraper, brush and vacuum cleaner, through the upper side
and trough the front door clean exchanging surfaces(F,G).
5. When you have finished cleaning, set upper door back to
original position and tighten them well, then set the top cover
back to position and close the front door of the boiler. Then press
''back'' on the regulation (
mode.
Cleaning interval
At least once per year
1
1. Maintenance
1.
Man. Boiler Cleaning
2.
Filling feeder screw
3.
Airvent
1. Press ''Maintenance'' on the regulation and then ''Cleaning the boiler''.
2. Press ''START'' (it will start the fan and it will open a grate.)
3. Lift the top cover (D), then unscrew the four screws
and remove the upper door (E).
4. By using scraper, brush and vacuum cleaner, through
the upper side clean exchanging surfaces(F,G).
5. When you have finished cleaning, set upper door back to
original position and tighten them well, then set the top cover
back to position. Then press ''back'' on the regulation (
return boiler to normal mode.
Technical instructions PelTec-lambda
Boiler type
12 kW
2
Man. Boiler Cleaning
2000
15k
0%
) to return boiler to normal
Metal vacuum cleaner
Boiler type
18-48 kW
2
Man. Boiler Cleaning
2000
15k
0%
Metal vacuum cleaner
Description
Cleaning of exchanging surfaces
(around the entire boiler)
Metal
tube
Description
Cleaning of exchanging surfaces
(around the entire boiler)
Metal
F F
tube
) to
Cleaning intervals
D
E
F
G
12 kW
D
E
G
G
18-48 kW
