Grate cleaning
1.5.1. MOUNTING MECHANISM FOR GRATE CLEANING
1. Remove the three screws (A), from cover (B) of the grate cleaning mechanism and remove cover
carefully .
B
B
A
2. Remove the two screws (C) and just slightly loosen screws (D) as shown in picture below.
Carefully attach grate cleaning mechanism to loose screws (D), then fasten with screws (C) and
tighten the screws (D).
C
D
C
D
12
Technical instructions PelTec-lambda
