3.4 Key Lock Function

Press the combined keys
and VFD will display a Lock label. In this functional state, all keys except the
following keys are invalid. Pressing
cancel the lock.

3.5 Short-circuit Analog Function

The electronic load can simulate a short circuit at the input terminal to test
whether the protection function of the DUT can operate normally when the
output terminal of the DUT is short-circuited.
Press
operation does not affect the current set value. When you press
(Short) again, the electronic load returns to the original setting state.
In the short-circuit status, the actual consumed current value depends on the
operating mode and current range of the load. In CC, CW and CR modes, when
the current is within the maximum range, the short-circuit current is the input
current value. When the current exceeds the maximum range, the maximum
short-circuit current is 110% of the range. In the CV mode, the short circuit is
equivalent to setting the constant voltage value of the load to 0V.

3.6 System Menu (System)

Press
POWER-ON
POWER-ON
BUZZER
BUZZER
SOURCE
TRIGGER
MEMORY
MEMORY
USB
COMM
RUN
RUNMODE
(Shift)+1 (Short) to switch the short circuit condition. The short-circuit
(Shift)+ (system) to enter the system menu.
RST(default)
SAV0
ON(default)
OFF
MANUAL(Def)
EXTERNAL
BUS
GROUP= 0
TMC / VCP
NORMAL
BATTERY
PROG_TEST
OCP_TEST
OPP_TEST
Copyright © Itech Electronic Co., Ltd.
(Shift)+ (Lock) to lock the front panel keys,
, Shift, Local (Lock) again will
Power on state of instrument
When the load is powered on, set the input
parameters to the factory state.
When the load is powered on, set the input
parameters to the value of SAVE 0.
Buzzer status setting
Enable audible beep when key is pressed.
No sound when key is pressed.
Set trigger mode
Triggered from the [Shift] + [.] key.
Triggered from a TTL high signal at the trigger
connector on rear panel
Triggered from a serial bus command 5AH
Use with the Recall button to
call up the stored parameters.
0: indicates1-10 groups;
1: indicates 11-20 groups, and so on
It supports two communication methods, TMC
and VCP. If VCP is selected, the built-in
device communication
9600/8/N/1.
Running mode at power on
Normal mode
Default in battery test mode at power on
Default in automatic test mode at power on
Default in OCP test mode at power on
Default in OPP test mode at power on
Functions and Characteristics
(Shift)+1
parameters are
