Chapter1 Inspection and Installation

1.1 Verifying the Shipment

Unpack the box and check the contents before operating the instrument. If
wrong items have been delivered, if items are missing, or if there is a defect with
the appearance of the items, contact the dealer from which you purchased the
instrument immediately. The package contents include:
Checklist of Package Contents
Item
Programmable
Electronic Loads
Power cord
USB cord
Test board of
quick charge
Factory
calibration report
Certificate of
conformity

1.2 Instrument Size Introduction

The instrument should be installed at well-ventilated and rational-sized space.
Please select appropriate space for installation based on the electronic load
size.
IT8500G+ series electronic load different models are not the same size, the detail
size of the electronic load is shown as below.
IT8511G+/IT8511AG+ Model
Qty.
DC
x1
x1
x1
x1
x1
x1
NOTE
Upon verification of the shipment, keep the package and relevant contents thereof in a
safe place. When returning the instrument for warranty service or repair, the specified
packing requirements shall be met.
Copyright © Itech Electronic Co., Ltd.
Model Remarks
IT8500G+ series include:
IT8500G+
IT8511G+/IT8511AG+/IT8512
series
G+/IT8512BG+
User may select an appropriate
IT-E171/IT-E17
power cord that matches the
2/IT-E173/IT-E
specifications of power socket
174
used in the area. See the
Section 1.7 Connecting the
Power Cord for details.
It is used when the
-
communication between the
device and the PC is realized
through the USB interface.
This is the standard
IT-E164
configuration of the IT8511AG+
model and is used for quick
charge testing. IT8511G+
models need to be equipped
with it.
It is the test report of the
-
instrument before delivery.
- -
Inspection and Installation
