ADEY DEK1001 MODBUS PROTOCOL – VARIABLE LIST
DEFAULT SETTINGS
BAUD RATE 9600
WORD LENGTH 8
PARITY NO
STOP BITS 1
X Variable Denomination
Address
40001 Cartridge Present
40002 Magnet Only Service
warning
40003 Magnet Only Service
warning Duration
40004 Parameter Pressure
Difference Warning
40005 Parameter Pressure
Difference
40006 Parameter Sensor
Minimum Pressure
40007 Parameter Maximum
Pressure
40008 Parameter Temperature
Alarm Enable
40009 Parameter Low
Temperature Alarm
40010 Parameter High
Temperature Alarm
40011 Parameter Pump
Required
40012 Parameter Current
Sense Active
40013 Parameter Alarm Relay
Contact Type
40014 Parameter Pump Hours
40015 Parameter ID Number
40016 Parameter Battery
Activated
40017 Parameter Expansion
Board Present
40018 Parameter Minimum
Flow Alarm
40019 Parameter Maximum
Flow Alarm
40020 Actual Day
40021 Actual Month
40022 Actual Year
40023 Actual Time Hour
40024 Actual Time Minute
40025 Service Date Day
40026 Service Date Month
40027 Service Date Year
40028 Last Serviced Date Day
Type X Variable Data Conversion
Format
read/write word 16 bits 4 = No 5 = Yes
6 = Fast Fast
read/write word 16 bits 11=Daily
12=Weekly
13=Monthly
read/write word 16 bits Value = X
read/write word 16 bits Value = X/10
read/write word 16 bits Value = X/10
read/write word 16 bits Value = X/10
read/write word 16 bits Value = X/10
read/write word 16 bits 4 = No 5 = Yes
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits 4 = No 5 = Yes
read/write word 16 bits 4 = No 5 = Yes
read/write word 16 bits 0 = Normal Open;
1 = Normal Close
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits 4 = No 5 = Yes
read/write word 16 bits 4 = No 5 = Yes
read/write word 16 bits not used
read/write word 16 bits not used
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read word 16 bits Value = X
read word 16 bits Value = X
read word 16 bits Value = X
read word 16 bits Value = X
Units Equivalent Range of
Range X Variable
4->6 4->6
11->13 11->13
1->12 1->12
Bar 0,1-0,6 1-6
Bar 0,1-6,0 1-60
Bar 0 - Par.7 0- Par.7
Bar Par.6-6,0 Par.6-60
4-5 4-5
°C 0°-Par.10 0°-Par.10
°C Par.10-120° Par.10-120°
4-5 4-5
4-5 4-5
0-1 0-1
h 0-9999 0-9999
0-99 1-99
4-5 4-5
4-5 4-5
1-31 1-31
1-12 1-12
0-99 0-99
0-23 0-23
0-59 0-59
1-31 1-31
1-12 1-12
0-99 0-99
1-31 1-31
Notes
See
note 1
See
note 2
See
note 3
See
note 4
