- Page 1 CK446300TX For assistance with assembly contact: Arnold Console Southern Enterprises, Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#：13499 Page1...
- Page 2 Arnold Console Parts list Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Arnold Console Assembly Instructions Screw with finger to help align bolts before using screwdriver. Connect 3 Legs (B) to Top Frame (A) with Bolts (1), Spring Washers (2) and Flat Washers (3). Tighten Bolts (1) with Phillips screwdriver. Warning: Do not over-tighten Bolts (1).
- Page 4 Connect the last Leg (B) to the assembled unit with Bolts (1), Spring Washers (2) and Flat Washers (3). Tighten Screws (4) with Phillips Screwdriver. Tighten Screw (4) through corresponding holes on Bottom Rail (D) and into Bottom Panel (C), Tighten all bolts and screws with Phillips screwdriver.
- Page 5 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
