- Page 1 BARBECUE RANGE GRANDE Part Number 552839 Dimensions Width 1600 mm Depth 600 mm Height 1250 mm Market Introduced - Aug 2014 "NEW" 2015 Issue C.0 ECN 11996 Dec 2015 PB REF # 752839...
- Page 2 Knob-Control, Main Zinc Alloy 547176 *Channel- Window, Hood 31a 559778 *Insert- Knob, 6.3mm Stem 547619 *Temperature Gauge 559229 *Badge- MASPORT 559371 *Handle- Hood 547664 *Rubber Stopper, 15dia x 6mm Spares Note. __==__ Insert 559778 can be used in knobs 559340 & 559341 559638 Pin- Hinge &...
- Page 3 Issue C.0 ECN 11996 Dec 2015 PB GRANDE REF # 752839 Item Part Description Item Part Description 559579 Pipe- Flexible, Front R/B 559564 Rack- Warming, RB 559566 Bezel- Control Knob, Small 559581 Panel- Rear Cover, RB SS 1 559565 Knob- Control, Small S/G 559573 Pipe- Flexible, RB 547238...
- Page 4 Issue C.0 ECN 11996 Dec 2015 PB GRANDE REF # 752839 Item Part Description Item Part Description 559321 Apron- LH 559329 Panel- Top, Front 559320 Apron- Front, 559723 Bracket- Top Panel, Trolley 559571 Weight- Bottom Panel 559722 Panel- Top, Trolley 559328 Panel- Side, RH 559358...
- Page 5 Issue C.0 ECN 11996 Dec 2015 PB GRANDE REF # 752839 559218 Rotisserie Set 210 Series 559239 Motor- Rotisserie 556297 Prongs 559223 Rod Only-Motor Side(550mm) 559224 Rod Only-Handle Side(400mm) 559497 Alignment Collar & Screw 559769 Handle (6mm thread) 559494 Bracket- Rotisserie When ordering PLEASE QUOTE PART NUMBER &...
- Page 6 1-37 Mt Wellington Highway, Panmure, Auckland 1060, New Zealand PO Box 14349, Panmure Auckland USE OUTDOOR ONLY 1471, New Zealand MASPORT AUSTRALIA PTY LIMITED WARNING: Parts of this appliance 1/40 Abbotts Road, Dandenong South, may be very hot, keep young Manufactured by:...
-
Page 7: Optional Extras
Issue C.0 ECN 11996 Dec 2015 PB GRANDE REF # 752839 Optional Extras 547137 Interchangeable Cooking System P/E Gloss 1 555231 *Kebab Rack (each) 547136 *Grill, P/E Gloss (390 x 485) 559761 *Kebab Skewers 559762 *Pizza Stone 547134 *Grill Insert, P/E Gloss 547135 *Plate Insert, P/E Gloss 547223... - Page 8 Issue C.0 ECN 11996 Dec 2015 PB GRANDE REF # 752839 Optional Extras Con't 547247 KIT- Conversion, Natural Gas - 210 Series 547042 Valve- Main Ignition, NG Integrated Ign 547245 Valve- Rear Burner, NG Electronic Ign 547045 Valve- Side Burner, NG Integrated Ign 547051 Hose &...
