MASPORT 4 BURNER
www.masport.com
OWNER'S MANUAL
Please read these instructions carefully before assembly, to
reduce risk of fire, burn hazard or other injury.
Keep these instructions in a safe place for future use.
This manual covers the Masport Ambassador Deluxe 210 barbecue.
Part N
: 559307
o
Advertisement
Table of Contents
Related Manuals for Masport Barbecues 210
Summary of Contents for Masport Barbecues 210
- Page 1 Please read these instructions carefully before assembly, to reduce risk of fire, burn hazard or other injury. Keep these instructions in a safe place for future use. This manual covers the Masport Ambassador Deluxe 210 barbecue. www.masport.com Part N : 559307...
-
Page 2: Table Of Contents
Keep the instructions in a safe place for future use. Important Safety Information Contents Please read and understand this manual fully before assembly and use. Safety Information • The Manufacturer’s Warranty may be voided by the incorrect use Parts of this product. Assembly instructions 6-10 •... - Page 3 For your safety If you smell gas: Shut off the gas supply to the barbecue. Extinguish any open flame. Clear the area to allow the unburnt gas to dissapate. Be aware of the reason for the gas smell, address this before continuing.
-
Page 4: Parts
Parts... - Page 5 Apron- RH 559405 559452 Pipe- Gas, Infrared Burner Bracket- Door Stop 37 & 559407 Bracket Set- LH/RH, 559229 Badge- Masport, Large W/ Rack 559409 Body- Main, Shell Only NOT ILLUSTRATED 559410 Manifold- Valve Assy “AUS” 559672 Deep dish (accessory) 559098 559403 Manifold- Valve Assy “NZ”...
-
Page 6: Assembly Instructions
Assembly Instructions Loosely fit the Front Apron to the trolley bottom panel using three M5x45 screws. (Do not tighten the screws at this moment, leave loose for adjusting for the left and right apron assembly.) Fit the two tabs of the Front Apron into the slotted holes of the Left Apron. Lift the Left Apron up to make sure it is flush with the edge of the bottom panel and front Apron. - Page 7 Fix the Left Apron into the bottom panel using three M5x10 screws and tighten these screws firmly. Repeat the same method for the Right Apron. Tighten these screws firmly. Then tighten the three M5x45 screws from the first step. Fitting the Side Table handle onto the RH Side Table using six M5x10 screws. Tighten the screws firmly. RH Side Table...
- Page 8 Loosen the top two M6x12 screws assembled into the RH Grill Body side panel, keep 5mm clearance between screw head and the panel, remove the lower M6x12 screws. Attach the RH Side Table onto the protuding M6 screws. Fasten two M6x12 screws through the lower fastener holes. Tighten the top two M6x12 screws which are still loose from the 6th step. Place the Marble Insert into the RH Side Table.
- Page 9 10. Fix the wire rack wire ends in the back panel holes as shown in the diagram 11. Fix the wire rack legs in to the bottom panel using M5x10 screws 12. Open the hood and place the flame tamer as shown in the diagram Rotisserie - Assembly Instructions Tools needed for assembly Crosshead screwdriver, 10mm A/F spanner...
-
Page 10: Fitting The Batteries For The Led Lights
13. Place the cooking grill, cooking plate/deep dish and warming rack to the frame body as shown in the diagram Motor Holder Fitting the Batteries for the LED Lights on the Barbecue GAS BOTTLE MUST BE REMOVED FROM CABINET TO CARRY OUT THE STEPS BELOW Removing the battery holder from BBQ The battery holder is located in the top of the cupboard in which the gas bottle is located (see diagram below). -
Page 11: Location Information
Installation SELECTING A LOCATION This barbecue is for outdoor use only and should be placed in a well-ventilated area. Take care to ensure that the minimum clearances guidelines are followed: Minimum clearances: From sides: 430mm; From back: 430mm From above (vertical): 1000mm Keep this barbecue away from any flammable materials! This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage... -
Page 12: Leak Testing
As the POL regulator is fitted with a soft nose, it should only be The “lo” position is obtained by turning the knob tightened a further 1/4 turn after resistance is first felt. fully anti-clockwise. Adjusting the control knob to your heat LEAK TESTING requirements can now control the flame. -
Page 13: Care And Maintenance
GRIDDLE PLATE / FLAT-FREE PLATE (where supplied) FLARE-UP CONTROL The burners heat the griddle plate directly, which then cooks the Flare-ups occur when meat is barbecued, and its fats and juices food on contact. These allow for the cooking of smaller items, such fall upon the flame tamers. - Page 14 steel wool should be avoided as they may leave particles embedded CAST IRON COOKING SURFACES on the surface which can lead to RUSTING. Cleaning should always Scrub the cooking surfaces with a brass wire brush to remove food be followed by rinsing in clean hot water. residue.
-
Page 15: Troubleshooting
To protect your investment it is recommended that BBQs are protected by a suitable BBQ cover. But please note that prior to using a protective cover, the BBQ should always be cool, cleaned of any surface contaminant or dirt and be thoroughly dry. -
Page 16: Technical Data
Gas Type: AUS: FOR PROPANE USE ONLY Minimum Clearance : From Top of BBQ : 1000mm, From Sides : 430mm, From Rear : 430mm Read the instructions before using the appliance Distributed by MASPORT Ltd Manufactured by: USE OUTDOOR ONLY... - Page 20 Head Office - New Zealand 1-37 Mt Wellington Highway. Panmure, P.O. Box 14 349 Auckland 1060, New Zealand...
