- Page 1 OUTDOOR BBQ ORIGIN DELUXE Part Number BBQ Dimensions: 553225 (Aus) Width 1600mm 553226 (N-Z) Depth 670mm Height 1200mm Month and Year of Manufacture: July 2021 Issue A.0 May 2021 PB ECN # 12800 IPL Ref # 753225...
- Page 2 Issue A.0 May 2021 PB 553225 & 553226 ECN # 12800 BBQ - ORIGIN DELUXE IPL Ref # 753225 Item Part No Description Item Part No Description 546914 Hood Assy Full-Wndow, 2021 SS/SS 1 559778 Insert- Knob, 6.3mm 548705 Insert- Knob, 8.0mm...
- Page 3 548703 Knob- BBQ, 8.0 S/Grip Zinc 559581 Panel- Rear Cover, RB 559339 Bezel- Control Knob 559573 Pipe- Flexible, RB 546928 Dashboard- BBQ Origin Deluxe 549761 Jet, RB 0.98mm 548783 Panel- H/Shield, Frnt(Smoke)6B+RB 1 559575 Nut- Jet Retainer, RB 559353 Panel- Heatshield, Side...
- Page 4 Issue A.0 May 2021 PB 553225 & 553226 ECN # 12800 BBQ - ORIGIN DELUXE IPL Ref # 753225 Item Part No Description Item Part No Description 548600 Drawer 559321 Apron- LH 1a 549787 Drawer- Fascia Panel 559320 Apron- Front,...
- Page 5 Issue A.0 May 2021 PB 553225 & 553226 ECN # 12800 BBQ - ORIGIN DELUXE IPL Ref # 753225 Data Plate 546943.b.0 IAPMO Injector Pressure Total Name Model Inp/Burn (MJ/h) Approval (mm) (kPa) (MJ/h) 0.93 6 x 11.70 ULPG: 2.75 81.19...
- Page 6 Issue A.0 May 2021 PB 553225 & 553226 ECN # 12800 BBQ - ORIGIN DELUXE IPL Ref # 753225 Optional Extras Continued 547137 Interchangeable Cooking System P/E Gloss 555231 *Kebab Rack (each) 547136 *Grill, P/E Gloss (390 x 485) 559761 *Kebab Skewers...
