- Page 1 User Guide PowerCage Products PowerCage MTP AV Series ™ MTP Twisted Pair Transmitter and Receiver Modular Boards 68-1643-01 Rev. A 08 10...
- Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated on the product. This This symbol is intended to alert the user of important operating and mainte- equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third nance (servicing) instructions in the literature provided with the equipment.
- Page 3 CAUTION: A Caution warns of things or actions that might damage the equipment. WARNING: A Warning warns of things or actions that might cause injury, death, or other severe consequences. Copyright © 2010 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners.
-
Page 4: Table Of Contents
Contents Reference Information ......Introduction ..........Specifications ........... 8 About this Guide ..........1 Part Numbers ..........10 About the PowerCage MTP AV Transmitters PowerCage MTP AV Part Numbers ..... 10 and Receivers ..........1 Included Parts ..........10 Features ............2 Cables and Connectors ...... -
Page 5: Introduction
Introduction • About this Guide • About the PowerCage MTP AV Transmitters and Receivers • Features About this Guide This guide contains information about the following Extron PowerCage MTP AV modular ® ™ board-designed twisted pair transmitters and receivers that are compatible with the PowerCage Modular Power Enclosure: •... -
Page 6: Features
Features • PowerCage MTP T AV transmits composite video or S-video along with summed mono audio signals 1,000 feet (300 meters) or more over a single CAT 5, 5e, 6, or Extron Enhanced Skew-Free UTP cable. ™ • Compatible with NTSC, PAL, and SECAM •... -
Page 7: Installation And Operation
Installation and Operation This section describes the installation and operation of the PowerCage MTP T AV and MTP R AV, including: • Installing the Boards into the PowerCage Enclosure • Connections, LEDs, and Encoders • PowerCage Front Panel Port, Control, and Indicators •... -
Page 8: Connections, Leds, And Encoders
Carefully slide the board into the slot, aligning that the two tabs on the lower front end of the board with the matching ports in the enclosure. Push the board firmly into place. If the PowerCage is powered on, the power LED on the board lights. Tighten the screws to secure the board in place. - Page 9 NOTES: The length of exposed wires is critical. The ideal length is 3/16 inch (5 mm). If the stripped section of wire is longer than 3/16 inch, the exposed wires may touch, causing a short circuit. If it is shorter than 3/16 inch, wires can be easily pulled out of the captive screw connectors.
-
Page 10: Powercage Front Panel Port, Control, And Indicators
PowerCage Front Panel Port, Control, and Indicators For full details on the mounting, setup, and operation of the PowerCage 1600 enclosure refer to the PowerCage 1600 Enclosure User Guide, online at www.extron.com. The following features are on the front panel of the PowerCage enclosure. COMM COMM SELECT... -
Page 11: Operation
Temp LED — This LED lights to indicate that the temperature within the PowerCage enclosure is high (approximately 167 °F [75 °C]) and equipment damage is imminent . Operation After the transmitter, all receivers, and their connected devices are powered up, the system is fully operational. -
Page 12: Reference Information
Reference Information This section provides the specifications and part numbers for the PowerCage MTP T AV and Powercage MTP R AV modular boards. • Specifications • Part Numbers Specifications NOTE: For PowerCage Enclosure specifications, refer to the PowerCage 1600 Enclosure User Guide, or to the PowerCage system specifications, available online at www.extron.com. - Page 13 Audio input — PowerCage MTP T AV Number/signal type ......1 stereo, unbalanced Connector ........(1) 3.5 mm captive screw connector, 5 pole Impedance ........>10k ohms, unbalanced: >20k ohms, balanced: AC coupled Nominal levels ........ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms) Maximum level .......
-
Page 14: Part Numbers
Part Numbers PowerCage MTP AV Part Numbers The PowerCage MTP AV boards must be installed in a PowerCage 1600 enclosure. PowerCage Enclosure and Boards Part number PowerCage MTP T AV 70-815-01 PowerCage MTP R AV 70-816-01 Included Parts These items are included in each order for a PowerCage MTP T AV and MTP R AV: Included parts Part number IEC power cord... - Page 15 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
