If this initial configuration doesn't meet your local requirements, you need to do the initial IP
configuration. Use one of the following ways:
1. Connect the enclosed NULL modem cable to the serial interface on the rear side. The serial
interface needs to be adjusted with the parameters shown in table 1-2:
Use a terminal software (e.g. hyper term or minicom) to connect to IP-KVM switch. Reset IP-KVM
switch and immediately press < ESC >. You will see some device information and a '=>' prompt.
Enter the command 'config' and press < Enter >. After waiting a few moments you may configure IP
auto configuration, IP address, net mask and default gateway. Pressing < Enter > without entering
values does not change settings. The gateway value must be set to 0.0.0.0 (for no gateway) or any
other value. You will be asked if the values are correct and get a chance to correct them. After
confirming, IP-KVM switch performs a reset.
2. Use a crossover Ethernet cable to connect IP-KVM switch to a subnet where a DHCP server is
available. After the DHCP server has assigned an IP address to IP-KVM switch you can use the web
interface to configure the device.
Web interface
IP-KVM switch may be accessed using a standard JAVA enabled web browser. You may use the
HTTP protocol or a secure encrypted connection via HTTPS. Just enter the configured IP address of
IP-KVM switch into your web browser.
Changing these settings to user specific values is strongly recommended
and can be done on the User Management page (see the Section called
Users and Groups in Chapter 6 ).
Remote Console
The Remote Console is the redirected screen, keyboard and mouse of the remote host system to
which IP-KVM switch is installed. The web browser which is used for accessing IP-KVM switch has to
Parameter
IP auto configuration
IP-Address
Net-mask
Default-Gateway
Table 1-1: Initial configuration
Parameter
Bits/second
Data bits
Parity
Stop bits
Flow Control
Table 1-2: Serial parameters
Login name
super (factory default)
Password
pass (factory default)
Value
DHCP
192.168.1.22
255.255.255.0
none
Value
115200
8
No
1
None
5
Single port KVM over IP switch
