Make sure that the cable is wired appropriately for a standard 100BASE-TX adapter.

Align the RJ-45 plug with the notch on the adapter's connector and insert it into the

adapter's connector.

3.3 Scenario of connecting IP-KVM switch to the Multi-port KVM Switch system

3.4 Connecting the External Reset/Power Option

Please refer to the manual of the IP-KVM 8/16/32 port external power switch option or a third

party external power option to connect those external devices to one of the serial interface on the

rear side of IP-KVM switch. By the date of printing this manual supported options are:

. Avocent.SPC1 800/1600

Sentry In-Line Power Module

Leaning ePowerSwitch

Peppercon IPM-220L
