The user " super " is not allowed to login via the serial interface of the IP-KVM switch.
Please make sure to change the super user password immediately after you have
installed and accessed your IP-KVM switch for the first time. Not changing the pass
phrase for the super user is a severe security risk and might result in unauthorized
access to the IP-KVM switch and to the host system including all possible
consequences!
Your web browser has to accept cookies, or else login is not possible.
Navigation
Having logged into the IP-KVM switch successfully, the main page of the IP-KVM switch
appears (see Figure 5-3). This page consists of three parts; each of them contains specific
information. The buttons on the upper side allow you to navigate within the front end (see
Table 5-2 for details). The lower left frame contains a navigation bar and allows you to switch
between the different sections of the IP-KVM switch. Within the right frame, task-specific
information is displayed that depends on the section you have chosen before.
Warning
Warning
Warning
Figure 5-3. Main page
Return to the main page of the IP-KVM
switch .
