Quick Guide for VLT Micro FC 51
Operation Keys:
A yellow light above the operation keys indicates the active key.
[Hand on]: Starts the motor and enables control of the frequency converter via the LCP.
[Off/Reset]: Stops the motor (off). If in alarm mode the alarm will be reset.
[Auto on]: The frequency converter is controlled either via control terminals or serial communication.
[Potentiometer] (LCP12):
converter is running.
Auto Mode
In the potentiometer acts as an extra programmable analog input.
Hand on Mode
In the potentiometer controls local reference.
▲ ▼
Arrows [ ] and [ ] toggles between the choices in each menu.
The display indicates the status mode with a small arrow above "Status".
The Quick Menu gives easy access to the most frequently used parameters.
1. To enter the Quick Menu, press [MENU] key until indicator in display is placed above
▲ ▼
2.
Use [ ] [ ] to select either QM1 or QM2, then press [OK].
▲ ▼
3.
Use [ ] [ ] to browse through the parameters in the Quick Menu.
4. Press [OK] to select a parameter.
▲ ▼
5.
Use [ ] [ ] to change the value of a parameter setting.
6. Press [OK] to accept the change.
7. To exit, press either [Back] twice to enter
No Name
1-20 Motor Power [kW]/[HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor nominal speed
1-29 Automatic Motor Tuning
(AMT)
3-02 Minimum reference
3-03 Maximum reference
3-41 Ramp up time 1
3-42 Ramp down time 1
1) M4 and M5 only
Table 1.5: Basic Settings Quick Menu 1
The Main Menu gives access to all parameters.
1. To enter the Main Menu, press [MENU] key until indicator in display is placed above
▲ ▼
2.
Use [ ] [ ] to browse through the parameter groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6.
Use [ ] [ ] to set/change the parameter value.
7. Press [OK] to accept the value.
8. To exit, press either [Back] twice to enter
The potentiometer works in two ways depending on the mode in which the frequency
Status , or press [Menu] once to enter
Range Default
[0.09kW/0.12HP -30kW/40HP] Unit dependent Enter motor power from nameplate data
[50 - 999V] 230/400
[20 - 400 Hz] 50
[0.01 - 100.00 A] Unit dependent Enter motor current from nameplate data
[100 - 9999 RPM] Unit dependent Enter motor nominal speed from nameplate data
[0] = off [0] = off
[2] = Enable AMT
[-4999 - 4999] 0
[-4999 - 4999] 50.00
[0.05 - 3600s] 3.00 (10.00
[0.05 - 3600s]
3.00 (10.00
Quick Menu
®
MG.02.B5.02 - VLT is a registered Danfoss trademark
Main Menu
Function
Enter motor voltage from nameplate data
Enter motor frequency form nameplate data
Use AMT to optimize motor performance.
1. Stop VLT
2. Choose [2]
3. "Hand On"
Enter value for minimum reference
Enter value for maximum reference
1) ) Ramp up time from 0 to rated motor frequency par. 1-23
1) Ramp down time form rated motor frequency par. 1-23
)
to 0
, or press [Menu] once to enter
