Quick Guide for VLT Micro FC 51
Brake resistors are available from Danfoss.
Improved power factor and EMC performance can be achieved by installing optional Danfoss line filters.
Danfoss power filters can also be used for load sharing.
1.3.9 Load sharing/Brake
Use 6.3 mm insulated Faston Plugs designed for high voltage for DC (Load Sharing and brake).
Contact Danfoss or see instruction no. MI.50.Nx.02 for load sharing and instruction no. MI.90.Fx.02 for brake.
Load sharing: Connect terminals -UDC and +UDC/+BR.
Brake: Connect terminals -BR and +UDC/+BR (Not applicable for frame M1).
Note that voltage levels of up to 850 V DC may occur between terminals
+UDC/+BR and -UDC. Not short circuit protected.
®
MG.02.B5.02 - VLT
is a registered Danfoss trademark
1 Quick Guide
1
7
