Danfoss VLT Micro FC 51 Quick Manual page 16

1 Quick Guide
1.7.3 Mains Supply 3 x 380 - 480 VAC
Normal overload 150% for 1 minute
1
Frequency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
IP 20
Output current
Continuous (3 x 380-440 V) [A]
Intermittent (3 x 380-440 V) [A]
Continuous (3 x 440-480 V) [A]
Intermittent (3 x 440-480 V) [A]
Max. cable size:
(mains, motor) [mm
Max. input current
Continuous (3 x 380-440 V ) [A]
Intermittent (3 x 380-440 V ) [A]
Continuous (3 x 440-480 V ) [A]
Intermittent (3 x 440-480 V ) [A]
Max. mains fuses [A]
Environment
Estimated power loss [W], Best case/
Typical
Weight enclosure IP20 [kg]
Efficiency [%], Best case/
Typical
Table 1.9: Mains supply 3 x 380 - 480 VAC
1. At rated load conditions.
Normal overload 150% for 1 minute
Frequency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
IP 20
Output current
Continuous (3 x 380-440 V) [A]
Intermittent (3 x 380-440 V) [A]
Continuous (3 x 440-480 V) [A]
Intermittent (3 x 440-480 V) [A]
Max. cable size:
(mains, motor) [mm
Max. input current
Continuous (3 x 380-440 V ) [A]
Intermittent (3 x 380-440 V ) [A]
Continuous (3 x 440-480 V ) [A]
Intermittent (3 x 440-480 V ) [A]
Max. mains fuses [A]
Environment
Estimated power loss [W], Best case/
Typical
Weight enclosure IP20 [kg]
Efficiency [%], Best case/
Typical
Table 1.10: Mains supply 3 x 380 - 480 VAC
1. At rated load conditions.
16
2
/ AWG]
1)
1)
2
/ AWG]
1)
1)
MG.02.B5.02 - VLT
PK37 PK75 P1K5
0.37 0.75 1.5
0.5 1 2
Frame Frame Frame
M1 M1 M2
1.2 2.2 3.7
1.8 3.3 5.6
1.1 2.1 3.4
1.7 3.2 5.1
4/10
1.9 3.5 5.9
2.6 4.7 8.7
1.7 3.0 5.1
2.3 4.0 7.5
See Section
18.5/ 28.5/ 41.5/
25.5 43.5 56.5
1.1 1.1 1.6
96.8/ 97.4/ 98.0/
95.5 96.0 97.2
P5K5 P7K5 P11K
5.5 7.5 11
7.5 10 15
Frame Frame Frame
M3 M3 M4
12.0 15.5 23.0
18.0 23.5 34.5
11.0 14.0 21.0
16.5 21.3 31.5
4/10
19.2 24.8 33.0
27.4 36.3 47.5
16.6 21.4 29.0
23.6 30.1 41.0
See Section
131.0/ 175.0/ 290.0/
166.8 217.5 342.0
3.0 3.0
98.0/ 98.0/ 97.8/
97.5 97.5 97.4
®
is a registered Danfoss trademark
Quick Guide for VLT Micro FC 51
P2K2 P3K0 P4K0
2.2 3.0 4.0
3 4 5
Frame Frame Frame
M2 M3 M3
5.3 7.2 9.0
8.0 10.8 13.7
4.8 6.3 8.2
7.2 9.5 12.3
8.5 11.5 14.4
12.6 16.8 20.2
7.3 9.9 12.4
10.8 14.4 17.5
Fuses
57.5/ 75.0/ 98.5/
81.5 101.6 133.5
1.6 3.0 3.0
97.9/ 98.0/ 98.0/
97.1 97.2 97.3
P15K P18K P22K
15 18.5 22
20 25 30
Frame Frame Frame
M4 M5 M5
31.0 37.0 43.0
46.5 55.5 64.5
27.0 34.0 40.0
40.5 51.0 60.0
16/6
42.0 34.7 41.2
60.0 49.0 57.6
36.0 31.5 37.5
52.0 44.0 53.0
Fuses
387.0/ 395.0/ 467.0/
454.0 428.0 520.0
97.7/ 98.1/ 98.1/
97.4 98.0 97.9
