User Manual
Version 1.0
English
Leica Zeno FLX100 Smart
Antenna

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zeno FLX100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Leica Zeno FLX100

  • Page 1 Leica Zeno FLX100 Smart Antenna User Manual Version 1.0 English...
  • Page 2 User antenna Manual. Provides an overview of the product User Manual together with technical data and safety directions. Refer to the myWorld web page for all Leica FLX100 smart antenna doc- umentation/software: https://myworld.leica-geosystems.com • myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a wide range of services, information and training material.
  • Page 3 Description myProducts Add all products that you and your company own and explore your world of Leica Geosystems: View detailed information on your products and update your products with the latest software and keep up- to-date with the latest documentation.
  • Page 4: Table Of Contents

    Firmware Upload Care and Transport Transport Storage Cleaning and Drying Technical Data Accessories Conformity to National Regulations 5.2.1 Dangerous Goods Regulations Leica FLX100 smart antenna Bundle Standard Configuration Accessories Packages for the FLX100 Smart Antenna Software Licence Agreement/Warranty Table of Contents...
  • Page 5: Safety Directions

    Safety Directions General Introduction Description The following directions enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid opera- tional hazards. The person responsible for the product must ensure that all users understand these directions and adhere to them.
  • Page 6: Definition Of Use

    Responsibilities Manufacturer of the Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica product Geosystems, is responsible for supplying the product, including the User Manual and original accessories, in a safe condition.
  • Page 7: Hazards Of Use

    To be familiar with local regulations relating to safety and accident pre- • vention To inform Leica Geosystems immediately if the product and the applica- • tion become unsafe To ensure that the national laws, regulations and conditions for the oper- •...
  • Page 8 DANGER Risk of electrocution Because of the risk of electrocution, it is dangerous to use poles, levelling staffs and extensions in the vicinity of electrical installations such as power cables or electrical railways. Precautions: ▶ Keep at a safe distance from electrical installations. If it is essential to work in this environment, first contact the safety authorities responsible for the electrical installations and follow their instructions.
  • Page 9 Risk of injuries to users and equipment destruction due to lack of repair knowledge. Precautions: ▶ Only authorised Leica Geosystems Service Centres are entitled to repair these products. For the AC/DC power supply: WARNING Electric shock due to missing ground connection If unit is not connected to ground, death or serious injury can occur.
  • Page 10 • Precautions: ▶ Do not open the product! ▶ Only Leica Geosystems authorised service centres are entitled to repair these products. CAUTION Unapproved chargers or cables Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty. Unapproved chargers or cables can cause the battery to explode or damage the device.
  • Page 11: Fcc Statement, Applicable In U

    • which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • CAUTION Changes or modifications not expressly approved by Leica Geosystems for compliance could void the user's authority to operate the equipment. Safety Directions...
  • Page 12: Ised Statements (En/Fr), Applicable In Canada

    Labelling Leica FLX100 smart Manufactured: 2020 antenna Manufactured: 2020 ZF10652000001E ZF10652000001E 0021266_001 ISED Statements (EN/FR), Applicable in Canada WARNING This Class (B) digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe (B) est conforme à la norme NMB-003 du Canada.
  • Page 13: Description Of The System

    Is designed to be used on the pole or on the Universal Handheld Tray. It • calculates a position from the computed ranges to all visible and activated GNSS satellites Can communicate with Leica Zeno GIS software: • Zeno Mobile, •...
  • Page 14: Instrument Components

    Instrument Components Description 21274_001 Connection LED – flashes blue when Bluetooth connected GNSS correction indicator – flashes green when receiving correction data Satellite LED – flashes green when position available Battery LED indicator – Solid green during normal operation – Flashing red when power < 10% –...
  • Page 15: Accessories

    Accessories Operation with pole Pole setup Leica FLX100 smart antenna AZ219 Pole Mount GLS30 Carbon Pole 21300_001 Operation with Using the AZ220 Universal Handheld Tray for FLX100 smart antenna smartphone Leica FLX100 smart antenna AZ220 Universal Handheld Tray Smartphone 21301_002...
  • Page 16: Operation

    Operation Power On/Off, Reset, Charging Description Power on/off button Battery LED indicator 21304_002 Function Description Power on/off Turn on: Press and hold the power button until the battery LED goes green and the device sounds a beep. ☞ The device starts booting after the first beep.
  • Page 17 Setup with Universal Use the Universal Handheld Tray to attach the FLX100 smart antenna with Handheld Tray phone/tablet - Art. 915868. The Universal Handheld Tray keeps the FLX100 smart antenna and phone/ tablet together. This setup maximises the productivity in the field. The Univer- sal Handheld Tray has a spring-loaded frame to hold a phone/tablet of differ- ent sizes.
  • Page 18: Phase Centre Of The Flx100 Smart Antenna

    Phase Centre of the FLX100 Smart Antenna Phase centre The phase centre of the FLX100 smart antenna location is at the dot near the top of the device. Pole mode In pole mode, the offset from the phase centre to the top of the pole, includ- ing the pole adapter mount, is automatically accounted.
  • Page 19: Configure Real-Time Corrections

    Configure Real-time Corrections Step-by-step This step-by-step procedure describes the configuration of the real-time cor- rection in Zeno Mobile and Zeno Connect. RTK Profile Wizard In Zeno Mobile Go to Settings within a project. Access GPS and then Realtime Cor- rections In Zeno Connect Open the app and go to Settings Go to Realtime Corrections...
  • Page 20: Firmware Upload

    FLX100 smart antenna. Download Firmware The latest firmware is always available on myWorld. ☞ https://myworld.leica-geosystems.com Download the firmware ZIP file from the FLX100 Firmware option in the Software section of the antenna in myWorld. Send Firmware to FLX100 smart antenna by Bluetooth Unzip the file "update.bin"...
  • Page 21: Care And Transport

    Shipping When transporting the product by rail, air or sea, always use the complete ori- ginal Leica Geosystems packaging, container and cardboard box, or its equival- ent, to protect against shock and vibration. Shipping, transport of When transporting or shipping batteries, the person responsible for the...
  • Page 22: Cleaning And Drying

    Cleaning and Drying Product and Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten • accessories the cloth with water or pure alcohol. Do not use other liquids; these may attack the polymer components. Damp products Dry the product, the container, the foam inserts and the accessories at a tem- perature not greater than 40 °C/104 °F and clean them.
  • Page 23: Technical Data

    Technical Data Instrument Type Description Satellites tracked GPS L1C/A, L2C QZSS L1C/A, L2C GLONASS L1OF, L2OF BeiDou B1I, B2I Galileo E1B/C, E5b Channels Update rate Up to 10 Hz Re-aquisition < 2 s RTK initialisation Typically > 120 s Cold start time Typically <...
  • Page 24: Accessories

    80 × 32 × 139 Weight Weight [g] Connector 1 USB Type-C connector, supports USB 2.0 Mounting Universal Handheld Tray Snap on handheld device and Leica FLX100 smart antenna Pole Leica FLX100 smart antenna mounted on Pole Adapter/Pole System Processor SC20...
  • Page 25: Conformity To National Regulations

    Leica Geosystems has developed Guidelines on “How to carry Leica ☞ products” and “How to ship Leica products” with Lithium batteries. Before any transportation of a Leica product, we ask you to consult these guidelines on our web page (http://www.leica-geosystems.com/dgr) to ensure that you are in accordance with the IATA Dangerous Goods Regulations and that the Leica products can be transported correctly.
  • Page 26: Leica Flx100 Smart Antenna Bundle

    AZ222 Arm/Belt pouch Soft bag for Leica FLX100 smart antenna, black Cardboard box Accessories Overview List of accesories available for the Leica FLX100 smart antenna: Part number Description AZ219 Pole Mount to attach the Leica FLX100 smart antenna with Pole...
  • Page 27: Packages For The Flx100 Smart Antenna

    The Pole is an optional accessory for the Leica FLX100 smart antenna. To use the Leica FLX100 smart antenna on a Pole, the appropriate adapter is required. This mounting allows customers to use the instrument vertically for precise and stable support.
  • Page 28 Part number, Description Package 6015970 Leica Zeno FLX100 smart antenna including: FLX100 Pole Multi-constellation support, • Start package GPS, GLONASS, Galileo and BeiDou with Zeno Mobile Power adapter • Type-C charging cable • Type-C USB cable • Arm/Belt pouch arm bag •...
  • Page 29: Software Licence Agreement/Warranty

    International Limited This product is subject to the terms and conditions set out in the International Warranty Limited Warranty which you can download from the Leica Geosystems AG home page at www.leica-geosystems.com/internationalwarranty or collect from your Leica Geosystems AG distributor.
  • Page 30 922526-1.0.0en Original text Published in Switzerland © 2020 Leica Geosystems AG, Heerbrugg, Switzerland Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com...
