- Page 1 Leica Zeno FLX100 plus Smart Antenna Quick Guide Version 1.0.1 English...
- Page 2 Important Information about your Instrument Read and follow the User Manual from the myWorld web page before using the product. https://myworld.leica-geosystems.com ☞ The User Manual is also stored in the internal memory of the FLX100 plus smart antenna. To locate it, establish a connection between a PC/Laptop and the FLX100 plus smart antenna using the USB cable.
- Page 3 • Precautions: ▶ Do not open the product! ▶ Only Leica Geosystems authorised service centres are entitled to repair these products. Trademarks Bluetooth® is a registered trademark of Bluetooth SIG, Inc. • All other trademarks are the property of their respective owners.
-
Page 4: Conformity To National Regulations
The full text of the EU declaration of conformity is available at the following Internet address: http://www.leica-geosystems.com/ce. FCC ID: RFD–FLX100PLUS FCC Part 15 Changes or modifications not expressly approved by Leica Geosystems for compli- ance could void the user's authority to operate the equipment. Canada CAN ICES-003 B/NMB-003 B IC: 3177A–FLX100PLUS... -
Page 5: Instrument Components
Instrument Components Description Connection LED Data link LED Satellite LED Battery LED indicator Power button USB type-C port 25010_001 Description Holes for the screws to fix the pole adapter 25101_001 Important Information about your Instrument... -
Page 6: Technical Data
Technical Data Technical Data Power Internal battery 3.8 V, 6120 mAh Type-C charging, supports 1.44 A fast charge Input voltage 5 V DC/2 A Working time > 20 hours Charge time Typically 4 hours Environmental Type Operating temperature [°C] Storage temperature [°C] specifications Instrument −40 to +65... -
Page 7: Care And Transport
Care and Transport Care and transport Carry the product in its original container to protect the product against shock and vibration. Technical Data... -
Page 8: Operation
Operation Operation ☞ The battery must be charged before using it for the first time. Turning on/off the Turn on: instrument Press and hold the power button until all LEDs switch on. The device sounds a beep when ready for use. Turn off: Press and hold the power button until all LEDs switch off and the device sounds a long beep. - Page 9 Connect the Receiver to the Device by Bluetooth Step-by-step Follow these steps to connect the FLX100 plus smart antenna to the device by Bluetooth. Open the Bluetooth settings on your device. Search for your FLX100 plus smart antenna with its serial number. Look up the target FLX100 plus smart antenna serial number on the back of the instrument.
- Page 10 Operation Attach the FLX100 plus Smart Antenna to the Pole Step-by-step Follow these steps to connect the FLX100 plus smart antenna to the pole. 25014_001 Use a slot screwdriver to fix the pole adapter with both screws to the FLX100 plus smart antenna. ☞...
- Page 12 970070-1.0.1en Original text (970070-1.0.1en) © 2024 Leica Geosystems AG Leica Geosystems AG Heinrich-Wild-Strasse 9435 Heerbrugg Switzerland www.leica-geosystems.com...
