Factory Settings - COMAC CAL FLOW 32 Installation And Technical Conditions

Factory configuration of outputs
OUT1 (impulse)
impulses in flow
direction
Table with flow ranges for individual DN sizes
Impulse constants and current loop – factory settings
Diameter
nominal
DN Vout[imp/l]
4 100
6 100
8 10
10 10
15 10
20 10
FLOW 32 manual
OUT2
impulses in reverse
flow direction
Diameter nominal
[mm]
DN 4
DN 6
DN 8
DN 10
DN 15
DN 20

Factory settings

Impulse output
Vout - pulse width [ms]
4
4
4
4
4
4
Page 14 (total 18)
OUT3
status output – Failure
Qmin Qmax
[m3/h] [m3/h]
0.02 0.5
0.03 1
0.04 2
0.06 3
0.2 7
0.25 10
4 – 20mA (in Qmin/Qmax 1/100 range)
Q[l/h] for 4mA
0
0
0
0
0
0
Analogue OUT
4-20mA in flow
direction
Q[l/h] for 20mA
540
1200
2200
3 400
7 600
14 200
COMAC CAL s.r.o.
