Summary of Contents for Resource Altea 90
- Page 1 Assembly Instructions Altea 90/120 Board...
- Page 2 Warranties for all products purchased from Resource Furniture, LLC are only valid if the product has been properly assembled, Installed by a trained professional, and operated in accordance with the assembly instructions. Resource Furniture accepts no responsibility for any damage or injury caused by Improper Installation.
- Page 3 ALTEA 90/120 BOARD OVERVIEW ALTEA 90 MATTRESS SPECIFICATIONS ALTEA 120 MATTRESS SPECIFICATIONS Recommended weight 31-35lbs Recommended weight: 46-51lbs Recommended dimensions: 33 1/2”x 78” x 7” Recommended dimensions: 45” x 78” x 7”...
- Page 4 ALTEA 90/120 BOARD OVERVIEW...
- Page 5 ALTEA 90/120 BOARD OVERVIEW Lower the right lever completely and verify that the two locking pins at the bottom of the bed base retract an equal distance and do so symmetrically. Repeat by operating the left lever.
- Page 6 HOW TO ADJUST THE LOCKING CABLE FOR MODEL PENELOPE/CIRCE/ALTEA ALTEA 90/120 BOARD ADJUST THE LOCKING CABLE 1. Loosen the locking nut as shown in the picture, Use a 10mm open end wrench.. 1. Loosen the locking nut as shown in the picture, Use a 10mm open end wrench..
- Page 7 ALTEA 90/120 BOARD COMPONENTS CODE QTY. COMPONENTS Right vertical panel Left vertical panel Top horizontal panel Bottom horizontal panel Bed frame Back panels Mattress support bar Desk Desk mechanism ALTEA 90/120 BOARD TOOLS QTY. DESCRIPTION Allen wrench 4 MM Allen wrench 5 MM...
- Page 8 ALTEA 90/120 BOARD STRUCTURAL HARDWARE Note: The installer must determine the composition of the wall and appropriate anchors prior to installation. The wall anchors included are for solid concrete walls only.
- Page 9 STRUCTURE ASSEMBLY...
- Page 10 STRUCTURE ASSEMBLY...
- Page 11 Wand Lighting OPTIONAL WAND LIGHTING Altea/Telemaco Installation Guideline for • Optional light fixture must be installed before headboard • Optional light fixture must be installed before headboard (see page 20-21 for details) • Drill 1/2” hole at 10 1/4” above headboard and 1 1/2” in from the side •...
- Page 12 LEVELING THE STRUCTURE Ensure that the structure is level and plumb. To compensate for any floor unevenness, use the adjustable feet on the bottom panel to level the structure.
- Page 13 WALL BED ATTACHMENT After the unit is level and plumb it should be securely attached to the wall using the metal angle mounting brackets as shown in the images below. A proper wall anchor suitable for the wall’s construction must be selected by the contractor or installer.
- Page 14 MATTRESS BAR INSTALLATION Mattress bar must be installed before the bed base is inserted into the structure.
- Page 15 BED BASE INSTALLATION...
- Page 16 BED BASE INSTALLATION BED BASE INSTALLATION...
- Page 17 DESK INSTALLATION...
- Page 18 DESK INSTALLATION...
- Page 19 DESK INSTALLATION...
- Page 20 MATTRESS INSTALLATION HEADBOARD AND MATTRESS INSTALLATION Open the bed to place the mattress and secure it with the straps...
- Page 21 BED OPERATION BED OPERATION OPENING CLOSING...
-
Page 22: Headboard Installation
HEADBOARD INSTALLATION Clean and dry the surface of the back panel. - Page 23 HEADBOARD INSTALLATION...
- Page 24 Make sure to support the bed frame for the entire descent until both legs are resting on the floor. NOTE: The Altea 90/120 Board will then be safely locked in place in the open position. Release the two mattress straps by squeezing the center of the clasp.
- Page 25 This indicates that the bed is now fully locked. Have a great day! NOTE: Your Altea 90/120 Board is designed so that most bedding can remain on the bed when closed. If you experience difficulty closing the bed, your bedding might be too thick.
- Page 26 ResourceFurniture.com...
