Summary of Contents for Resource Kali Duo

  • Page 1 Assembly Instructions Kali Duo...
  • Page 2 Do not install the bed on weakened or rotten structures. Warranties for all products purchased from Resource Furniture, LLC are only valid if the product has been properly assembled, Installed by a trained professional, and operated in accordance with the assembly instructions.
  • Page 3 KALI DUO OVERVIEW KALI DUO MATTRESS SPECIFICATIONS Recommended weight: ~ 31-35 lbs Recommended dimensions: W 31 1/2” X D 77 1/2” X H 7”...
  • Page 4 KALI DUO OVERVIEW...
  • Page 5 KALI DUO COMPONENTS CODE QTY. COMPONENTS Right side panel Left side panel Top horizontal panel Bottom horizontal panel Lower bed frame Upper bed frame Back panels Upper back panel (IN only) Structural shelf (IN only) Upper storage cabinet door (IN only)
  • Page 6 DESCRIPTION Connector bolts Cam connectors Phillips screw Hex screws - for attaching bed frame to structure For IN Upper Storage Cabinet KALI DUO WALL MOUNTING HARDWARE CODE QTY. DESCRIPTION Wall brackets Bracket screws Note: The installer must determine the composition of the wall and appropriate anchors...
  • Page 7 STRUCTURE ASSEMBLY Screw 8 (A) connector bolts into the (1) right vertical and (2) left vertical panels. Attach the (4) horizontal bottom panel ; (3) horizontal top panel and (9) structural shelf to the vertical panels by inserting and tightening 12 (B) cams. Insert black spline between the upper and lower back panels. Attach the (7) back panels to the structure with 44 (C) Phillips screws.
  • Page 8 Wand Lighting OPTIONAL WAND LIGHTING Kali Duo Installation Guideline for • Drill 1/2” hole at 37 7/8” measured from the bottom of the structure (from inside) and 1 Drill 1/2” hole at 37 7/8” measured from the bottom of the structure (from inside) and 1 1/2” in 1/2”...
  • Page 9 WALL ANCHORING INSTRUCTIONS Caution! ! Carefully read pages s 7-11 before anchoring the bed to the wall. It is compulsory to secure the product to intact and strong walls, by no less than 4 wall anchoring points, as well as to place it on leveled floors. 1 0 m m 0 m m...
  • Page 10 WALL ANCHORING INSTRUCTIONS After the unit is level and plumb it should be securely attached to the wall using the metal angle mounting brackets as shown in the images below. A proper wall anchor suitable for the wall’s construction must be selected by the contractor or installer. The required washer shown in the images below is not included with the hardware.
  • Page 11 WALL ANCHORING INSTRUCTIONS SHEETROCK For 1/2” and 5/8” thick sheetrock it is recommended to use (4) 3/16 strap toggles. Using a 1/2” (13 mm) diameter metal bit, drill into the drywall. Drywall Slide the metal channel of the anchor through the hole in the wall, hold the straps together and pull toward you until the channel rests behind the wall.
  • Page 12 WALL ANCHORING INSTRUCTIONS METAL STUDS : OPTIONAL Using a 1/2” (13 mm) diameter metal bit, drill into the drywall and the metal studs. Metal Drywall studs Slide the metal channel of the anchor through the hole in the wall, hold the straps together and pull toward you until the channel rests behind the wall.
  • Page 13 Put the wood screws #10 x 3 1/2” (89 mm) through the hole of the wall bracket and screw into the center of the studs until the wall bracket is pulled snug against the wall. 2” (50 mm) minimum Dryw Wood stud For any other wall materials please reach out to Resource Furniture.
  • Page 14 BED BASE INSTALLATION Mattress bar must be installed before the bed base is inserted into the structure. Fasten the 11 mattress support bars to the 5 lower and 6 upper bed frames using the 5MA x 20 screws attached to each bar. det.7a...
  • Page 15 LOWER BED BASE INSTALLATION At this stage of the installation the bed structure must be securely attached to the wall as described on pages 7-11. Position and insert the (5) bed frame within the structure as shown in det. 8a. det.8a det.8a...
  • Page 16 LOWER BED BASE INSTALLATION Close the lower bed and fasten 2 (D) hex screws into the mechanisms on both vertical panels, as shown in det. 9a. dett.9a...
  • Page 17 UPPER BED BASE INSTALLATION Position and insert the (6) upper bed frame within the structure as shown in det. 10a. det.10a det.10a...
  • Page 18 UPPER BED BASE INSTALLATION Close the upper bed and fasten 2 D hex screws into the mechanisms on both vertical panels, as shown in det. 11a. dett.11a...
  • Page 19 UPPER STORAGE ASSEMBLY Open the upper storage cabinet fully and attach the 4 hinges to the metal plates on the top panel. Attach the 2 (E) metal brackets to each side of the cabinet. Using an allen wrench, adjust the bracket so that it can fully support the weight of the storage door when open.
  • Page 20 UPPER PADDED BARRIERS ASSEMBLY Open the upper bed frame by pressing down on one of the two locking levers. 14a - Align the (16) long and (17) short padded barriers with the appropriate holes on the bed frame. 14b - Lift the barrier fabric as shown and fasten the barriers to the bed frame using 8 8MA x 50 screws 14c - Close the fabric.
  • Page 21 CLOSING UPPER PADDED BARRIERS The padded bed frames on the upper bed frame lock into upright position. In order to close the bed frame, you must first fold down the barriers. Close the barriers at the head and the foot of the bed by pushing the button as shown to disengage the lock and safely fold the barriers down on to the mattress.
  • Page 22 BOTTOM HEADBOARD INSTALLATION Open the lower bed frame by pressing down on one of the two locking levers. Remove the 2 caps from the end of the lower bed frame on which you wish to place the headboard. Fasten the headboard to the frame using the screws included with the headboard. dett.15a...
  • Page 23 REMOVABLE LADDER Ensure that both the upper and lower beds are open and locked in horizontal position. Position the ladder close to the metal slots on each bed frame. Gently tilt the ladder away from the structure, inserting the lower hooks into the slots on the lower bed frame (det. 15a). Straighten the ladder upright and insert the upper hooks into the slots on the upper bed frame (det.
  • Page 24 REMOVABLE LADDER To remove the ladder from the structure, pull the two pins at the top of the ladder (det. 16a) to unlock the mechanism, while simultaneously pulling the ladder hooks up and away from the slots. dett.17a...
  • Page 25 MAKING THE UPPER BED The Kali Duo bunk-bed system contains a mechanism that allows the upper bed frame to tilt downwards so that it is easy to make the bed. When the upper bunk is in its horizontal position, press down on one of the two locking levers and gently pull the bed downwards. To bring the bed back to its horizontal position, press down on one of the two locking levers and lift the bed upwards until it locks in place.
  • Page 26 SAFELY OPERATING YOUR KALI DUO BED Remove the sofa cushions. Locate the levers on either side of the beds. Release latch on either side of the beds with one hand, holding the top of the bed panel with the other.
  • Page 27 Just one more thing: You can stand on principle, but never stand on the sofa! NOTE: Your Kali Duo is designed so that most bedding can remain on the bed when closed. If you experience difficulty closing the bed, your bedding might be too thick.
  • Page 28 WARNING PAGE PROVIDED BY MANUFACTURER TRANSFORMING SYSTEM ASSEMBLY AND SAFETY CAREFULLY READ BEFORE PROCEEDING! Follow with care all points of the assembly procedure, as per technical sheets and their sequence showed in the following pages, and all the safety rules indicated. It is compulsory to fasten the product to intact and strong walls, by not less than 4 fixing points, and place it on perfectly levelled floors.
  • Page 29 CLEI SYSTEM MATERIAL REQUIREMENTS Attention to environmental issues and therefore our commitment to green design are our organization’s competitive advantages. We design and make our products choosing materials that have a low impact on the environment and bearing in mind methods for reducing consumption of materials and waste as well as energy savings.
  • Page 30 ResourceFurniture.com...
