Summary of Contents for Matsusada DJOP Series
- Page 1 Compact high speed bi-polar power supply DJOP Series Four-quadrant fast response bi-polar power supply DJOP series Output voltage : 0V to ±60V Maximum output power : 60W Frequency bandwidth : DC to 30kHz www.matsusada.com...
- Page 2 All the models are completely solid-state with output voltage between ±10V to ±60V. DJOP series is most appropriate for evaluation test such as solar panels, the instruments driven by battery and the IC which control battery.
-
Page 3: Specifications
Specifications Input voltage 85V to 264Vac / 50/60Hz / single phase Regulation Input : 0.05% (for ±10% input change) Load : 0.05% (for 10% to 100% load change) Input current 1.5A max @115Vac input External control voltage -10V to +10V Temperature coef. - Page 4 Dimensions inch(mm) / Functions Front Rear 5.51(140) POWER BIAS Vcon-in OUTPUT 4.88 (124) Side 0.59 0.91 (15) (23) 16.93(430) 4.88 (124) 0.31 POWER ON/OFF switch Bias ON/OFF switch OUTPUT ON/OFF switch Bias setting dial Output voltage meter Control connector Output current meter Output terminal CV/CC select switch AC input terminal...
-
Page 5: Response Speed
Options Door switch Remote switch When ordering, suffix the following option mark to the model number. <e.g> DJOP60-1-LDS (Alphabetical order) Characteristic of amplifier Rise time (Stepping time): The response time is sometimes described by the rise time (as shown in the drawing on the right). Vcon-in The rise time of an amplifier at a response speed of (= frequency bandwidth) Fc (Hz) is generally acquired by "tr 0.35/fc."... - Page 6 USA/canada : : +81-6-6150-5089 +81-6-6150-5089 other countries other countries : : Customer Inquiry Sheet (DJOP series) Please copy this page and above fax number after filling out form below. I would like A quotation An explanation of product A demonstration...
