Screw fixing seat x 2
M2.5x6 screw x 1
Integrated Wall bracket x 1
165.00 mm
C312A Front Panel
Reset Button
C312X Bottom
Front Bracket
ST4x20 screw x 2
C312 x 1
Speaker
LCD Screen
Wifi &Bluetooth LED
Numeric Keypad
Call Touch Key
Unlock Touch Key
Mic
Hangup Touch Key
Mute Touch Key
DND Touch Key
Volume Touch Key
6 Pin Port
10 Pin Port
Network Interface
(POE)
C312S Front Panel
C312X Rear Panel
102.00 mm
Rear Bracket
C312X
M4x30 screw x 2
6 Pin cable x1
10 Pin cable x1
Speaker
Numeric Keypad
Call Touch Key
Unlock Touch Key
Mic
Hangup Touch Key
Mute Touch Key
DND Touch Key
Volume Touch Key
Back Slot
Pogo Pin Signal Interface
Embedded Magnet
Pogo Pin
26.85
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Akuvox C312X
Summary of Contents for Akuvox C312X
- Page 1 Volume Touch Key C312S Front Panel C312A Front Panel Back Slot Pogo Pin Signal Interface Reset Button Embedded Magnet C312X Bottom C312X Rear Panel 6 Pin Port 10 Pin Port Pogo Pin Network Interface (POE) 102.00 mm 26.85 Front Bracket...
- Page 2 Installation Step 1: Integrated Wall Bracket Installation Without embedded junction box in the wall. According to the position of the cable, Place the integrated wall bracket in the Remove the integrated wall bracket cut a circular hole in the wall of the cut hole and adjust to the horizontal and use the 5 mm drill to drill 2 screw diameter of 68 mm and depth of 50...
- Page 3 Step 2: Device Installation Place the device carefully from top to bottom with its bottom part slightly away (up to 3 cm) from the wall. When the device fits to the bracket holder supports, push the device bottom part onto the bracket. Make sure the device was safety attracted to the magnets.
- Page 4 Notice Information Akuvox C312X firmware contains third-party open source software under the terms of the GNU General Public License(GPL). Akuvox is committed to meeting the requirements of the GNU General Public License (GPL) and will make all required source code available.
