2.
General Description of Ruby
2.1 General Overview
12
11
10
1- Hot Water Tap
2- Product Selection Buttons
3- Steam Tap
4 - Water Tank
2.2 Product Selection Buttons
Versión
Electrónica
a
d
a - One Coffee
b - Continuous Coffee
c - Two Coffees
2 3
1
4
9
8
Indicador nivel
5 - Power Switch
6 - Steam Arm
7 - Feet
8 - Drip Tray
b
c
e f
Water Supply
Element Wattage
Boiler Capacity
Tank Capacity
Water pump
5
6
7
9 - Drain Tray
10 - Boiler Pressure Gauge
11 - Filter Holder
12 - Hot Water Outlet
b
d e
d - Boiler Water Level Indicator
Boiler
e - Tank Water Level Indicator
f - Heating Element Indicator
18
15
Internal Tank
1.500 W (230 V)
1.5 L
3 L
Vibr. Pump 18 bar
A = 367 mm
B = 306 mm
C = 511 mm
A
B
C
Versión
Semiautomática
f
