OWNER'S MANUAL AND INSTALLATION GUIDE
SUBMERGED SUCTION OUTLET FOR MULTIPLE DRAIN USE FOR USE ON FLOOR
VGB Compliant ANSI/APSP/ICC-16 2017 LISTED
NOTICE
IMPORTANT SAFETY INSTRUCTIONS.
TO INSTALLERS: READ, UNDERSTAND,
AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS.
Give these instructions to the facility owner to keep for future reference. Follow all codes and
regulations that apply to the design, installation and use of suction outlet fittings.
WARNING
Any modification that increases the flow rate of the circulation system shall require reevaluation
of the cover/grate and sump to ensure that the flow rating of the Suction Outlet Fitting Assembly
(SOFA) is not exceeded.
https://www.1paramount.com/downloads/manuals/mdxr3/MDXR3CertificateOfConformity.pdf
SAVE THESE INSTRUCTIONS
004-027-8822-00
When installing and using this equipment, basic safety precautions
shall always be followed, including the following:
MDX-R3 and SDX2 must be installed in accordance with Paramount's
written instruction manual, and in conformity with applicable Federal,
State, Local and Swimming pool industry building and safety codes.
Certificate of conformity available at
8175 W. Buckeye Rd., Phoenix, AZ 85043
Toll Free: 1.800.621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397
Paramount@1Paramount.com • www.1Paramount.com
US and Foreign patents and patents pending
see www.1paramount.com/support/patent-numbers/
Paramount products are designed by Paramount in Phoenix, Arizona, United States of America
REV05 ECN_2006 PUB072921 ©2021 Hayward Industries, Inc.
MDX-R3 FOR VINYL POOLS
EUROPE
Advertisement
Related Manuals for Hayward Paramount MDX-R3
Summary of Contents for Hayward Paramount MDX-R3
- Page 1 Toll Free: 1.800.621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397 Paramount@1Paramount.com • www.1Paramount.com US and Foreign patents and patents pending see www.1paramount.com/support/patent-numbers/ Paramount products are designed by Paramount in Phoenix, Arizona, United States of America 004-027-8822-00 REV05 ECN_2006 PUB072921 ©2021 Hayward Industries, Inc.
-
Page 2: Signal Words And Symbols Used In This Manual
Signal Words and Symbols Used In This Manual This Owner’s Manual and Installation Guide contains specifi c precautions and symbols to identify safety- related information. You will fi nd DANGER, CAUTION, WARNING and NOTICE symbols which require special attention. Please read them carefully and follow these precautions as indicated! They will explain how to avoid hazards that may endanger you or persons using or maintaining your pool or spa. - Page 3 DEATH or SERIOUS INJURY will result from contact with a DANGER damaged, loose, or missing drain cover. • Do not allow limbs to contact or be inserted into a drain pipe with a damaged, loose, or missing drain cover. This could result in swelling of the limb and/or trapping a swimmer underwater.
- Page 4 Month 01 02 03 04 05 06 07 08 09 10 11 12 System fl ow rate ____________________________________ Installed location ____________________________________ 001-025-8818-00 ECN 2034 REV02 PUB 042221 ©2021 Hayward Industries, Inc. For technical assistance call 1.800.621.5886 or contact your regional representative...
- Page 5 MDX-R3 SYSTEM DESIGN These MDX-R3 instructions provide two methods to choose from, with additional methods for specific jurisdictions, (California specifically but not limited to that state). Your local codes may require additional safety measures. Paramount Pool & Spa Systems and its representatives cannot recommend or endorse installation methods other than those provided in these MDX-R3 instructions.
- Page 6 FLOW HEAD LOSS CURVE HEAD LOSS CURVE MDX-R3 (76) (151) (227) (303) (379) (454) (530) (606) (681) (757) FLOW RATE (LPM) MDX-R3 INSTALLATION WHEN USING A SKIMMER WITH CANISTER WITHOUT CANISTER MV FUSE MV FUSE IN DECK SIDE CANISTER TO PUMP & SDX2 SKIMMER BYPASS 2ND SUCTION OUTLET...
- Page 7 MDX-R3 INSTALLATION WITHOUT SKIMMER INSTALLED WITH CANISTER WITHOUT CANISTER MV FUSE IN MV FUSE DECK SIDE CANISTER TO PUMP SDX2 SDX2 2ND SUCTION OUTLET TRUNK LINE MUST BE 2ND SUCTION OUTLET SIZED TO MEET MAXINUM VELOCITY REQUIREMENTS TO PUMP FOR SUCTION PLUMBING PER LOCAL CODE.
- Page 8 MDX-R3 INSTALLATION MDX-R3 Plumbing (Fig. 1) Fig. 1 1. Position the MDX-R3 Sump even with the LINER finished depth of the pool, spa or basin POOL BASE (Fig. 1). Orientate the sump so the elbow is perpendicular to inside wall or end wall of pool. Whichever pool base is used, the drain sump must be encased in concrete as shown to anchor it in place.
- Page 9 MDX-R3 VINYL INSTALLATION Pool Base Install Finish pool base even with upper edge of MDX-R3 sump (Fig. 1). Liner Install 1. Make sure bottom gasket is in place before installing liner. 2. Set liner in pool and draw tight with vacuum. 3.
- Page 10 SDX2 VINYL INSTALLATION DO NOT USE POWER TOOLS TO INSTALL FASTENERS. Start all NOTICE fasteners by hand to prevent cross threading. Fig. 3 1. Select the installation location for the SDX2 drain. (Additional SDX2 drains may be used.) 2. For Steel Wall: Make one 4½” hole using a UP Arrow Greenlee®...
- Page 11 MDX-R3 WINTERIZATION WITH CANISTER If vacuum relief suction outlets are located below freeze line skip steps 1 and 2. 1. Remove grate from wall drain and install a 13-¾ blow through plug and blow line to achieve airlock. 2. If 3rd suction line is installed remove grate, install a 13-¾ blow-through plug and blow line to achieve airlock.
- Page 12 **Replace cover within 05 installed years. ***Replace all other components within 25 installed years MDX-R3 VINYL POOLS PART NUMBERS Item Part Number Description 005-252-2110-XX Cover (XX=Color Code)* Screw: No. 10 X 1” Security Head 005-252-8234-XX Funnel Assembly (Includes Support, Cover, Screw and Adapter)* Screw: No.
