NRS Healthcare MOWBRAY M11089 User Instructions

M11089
M92739
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1.

INTENDED USE

The Mowbray toilet frame and seat range is designed to assist those who have diffi culty in lowering onto or
rising from a standard toilet. The plastic moulded seat off ers support in a natural position and the frame is
height and width* adjustable.
(*Only available with M11089 – Mowbray width adjustable version).
2.

SPECIFICATION

1. One piece moulded plastic seat.
2. White epoxy coated frame.
3. Non-slip ferrules (free standing versions)
3.

SAFETY

WARNING: The maximum user weight must not be
more than 190Kg (30st).
DO NOT: attempt to stand or climb on the product.
MAKE SURE: all legs are set at equal height to
avoid rocking.
4.

UNPACKING

Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
MOWBRAY TOILET SEAT & FRAME RANGE
Mowbray Width Adjustable (Free Standing)
Mowbray Toilet Seat & Frame 510 (Free Standing)
USER INSTRUCTIONS
5.

FITTING INSTRUCTIONS

1. Remove the moulded seat from its polythene
bag and snap into place on the cross members
of the frame.
2. Ensure the seat is fi rmly in place and secure at
both back and front.
3. Adjust to the required height by removing each
'E' clip in turn.
4. Slide each leg up or down to the required
height. Align the holes in and replace 'E' clip.
5. The back legs can be set at a slightly higher
position than the front to help with ease of
transfer. (Height diff erence should not be more
than 2 holes).
6. Ensure that the two front legs are set at the
same height and the two back legs at the same
height position in order to prevent rocking.
7. Mowbray Width Adjustable only. (M11089). To
adjust the width, remove 'E' clip either side of
the seat and slide tubes to obtain the desired
width (ensuring equivalent holes are used on
each side of the seat so that the frame remains
square. Replace 'E' clips.
8. Place the Mowbray over the toilet with the
cutaway of the seat at the front and the integral
splash guard placed centrally over the toilet
bowl.
9. When not in use Mowbray's can be stacked
with the seat in situ. It is recommended that no
more than fi ve frames are stacked together for
long term storage.
1
Maximum User Weight
30st
190kg
