NRS Healthcare MOWBRAY LITE M66613 User Instructions

M66613 Flat Pack - Adjustable Width
M92740 510 - Fixed Width Assembled
General Safety Warning
Please make sure that you read and follow these
instructions carefully. Failure to do so can result in
injury. Keep these instructions in a safe place for
future reference.
INTENDED USE
The Mowbray Lite toilet frame and seat range is designed to assist those who have difficulty in lowering
onto or rising from a standard toilet. The plastic moulded seat offers support in a natural position and the
frame is height and width* adjustable.
(*Only available with M66613 – Mowbray Lite Flat Pack)
SAFETY
Read these instructions before installation and use.
This product must be correctly assembled, installed,
and maintained.
Do not exceed the maximum User Weight.
UNPACKING
Check product carefully before installation/use. If
you see, or suspect a fault, do not use, contact your
supplier immediately.
Note: M66625, M92740 & N36974 are delivered
ready assembled.
M66613 is supplied flat packed
USER INSTRUCTIONS
MOWBRAY LITE TOILET FRAME AND SEAT
RANGE
M66625 Standard - Fixed Width Assembled
N36974 Adjustable Width Assembled
Maximum User Weight
Contents (M66613 only):
1. Toilet seat x 1
2. Frame Side LH x 1
3. Frame Side RH x 1
4. Frame Centre Bar x 2
5. Leg Assembly x 4
6. E-clips x 8
ASSEMBLY
1. M66613 - Mowbray Lite Flat Pack:
Assemble the frame sides to the centre bars, set
to the correct width, align the holes and secure
with the four e-clips provided
2. N36974 - Mowbray Lite Adjustable Width As-
sembled:
The frame comes ready assembled. To set to
the width, remove e-clips and slide the frame
side tubes in the frame centre bars until the
desired width is achieved, align the holes and
secure using the four e-clips provided.
3. All Models
Remove the moulded seat from its protective
bag and snap into place on the centre bars of
the frame, ensure the seat is firmly in place and
secure at both back and front.
4. Adjust to the required height by removing each
'E' clip in turn and slide each leg up or down
to the required height. Align the holes in and
replace 'E' clip. (See diagram overleaf)
5. Ensure that all leg extensions are set at the
same height to prevent rocking.
1
30st
190kg
